Phương thức in |
*Truyền nhiệt/ chuyển nhiệt
*In kiểm soát đầu in |
Độ phân giải |
400 dpi/ 15.7 dot per mm |
Tốc độ in |
1"- 4"/sec.(15mm - 101mm/sec.) |
Độ rộng nhãn in |
4.15"/105mm |
Chiều dài nhãn in |
15.7"/400mm |
Bộ nhớ |
*8MB SDRAM
*4MB Flash |
Kiểu in nhãn |
*Die cut labels
*Butt cut Labels tags
*Tag stock
*Roll stock(Continuous s/o die cuts)
*Fan Fold |
Độ rộng cuộn giấy in |
*4.5"/116mm |
Độ dày nhãn in |
*0.0025" to 0.01"/0.0635mm to 0.254mm |
Đường kính Ribon thiết kế |
*Đường kính lớn nhất: 9.4"/240mm |
Đường kính Ribon thực tế |
*Đường kính lớn nhất: 2.95"/75mm |
Khoang chứa |
*Toàn bộ khoang chứa bằng thép. |
Màn hình LCD |
*Hiển thị 2 dòng 8 ký tự gồm chữ và số.
*Back Light |
Cảm biến |
*Ribbon sensor (Reflective method)
*Label sensor(Transmit method)
*Media Home position sensor
(Transmit-Auto calibration method) |
Thông báo lỗi thường gặp |
*Label/Ribbon empty
*Head open
*Communication
*Grammatical
*Parameter
(Each error is notified by buzzer and LCD |
Mã vạch |
*Code39, Code93, Code128, NW7, 2 of 5(Industrial, Matrix and
Interleaved), EAN-JAN 13/8, UPC-A/E, EAN128, QR Code,PDF417, Data
Matrix, Maxi Code, RSS |
Chế độ và chức năng in |
*Peel off, Tear off(demand type)with label back feed for top of label printing.
*Batch printing(Stip-for continous printing of labels. Can be used with optional External Rewinder)
*Butt cut label printing(Requires optional back side mark sensor) |
Tính năng ngôn ngữ lập trình |
*Advanced Label marking language-ALL
*ALL commmand are all ASCII characters. This allows flexibility with many environments and platforms
*Easy to program and format printing areas
*Pixel programming allows expanded area of up to 4 times
Four direction print rotation(0,90,180 & 270 degrees)
Reverse print and area fill in
*Mirror print
*Half Tones
*Lines, dotted lines, angle lines and boxes
Bit image data transfer and printing
*Downloadable graphics, text, font and formats to optional memory card
*Character Set(Code page)table
*Serializing(Numeric)
*Communication and print functions
*RLE data compression
*Graphic supported AIM, AIX, BMP, PCX(Monochrome only) |
Bảng điều khiển phía trước với chức năng điều chỉnh lựa chọn bằng phần mềm
|
*Print Speed/Energy Settings
*Print Density
*Label Print Position
*Cutting Position
*Thermal Transfer/Direct Thremal
*Test Printing
*Ready/Pause |
Cổng kết nối
|
*Parallel/USB
*RS232/to 115,200 baud rate, Line Control-RS-CS, XON-XOFF, ER-DR, Stop Bits, Parity, Data length |
Nguồn điện vào |
115 V +-10% AC50/60 HZ, 240 V +-10% AC 50/60 HZ |
Nhiệt độ, độ ẩm môi trường làm việc |
*Máy làm việc trong nhiệt độ: 5 - 40oC
*Độ ẩm không khí: < 85%
*Không đặt máy trong môi trường quá bụi và có chất ăn mòn. |
Lựa chọn thêm |
*Cutter(Slide type) - Dao cắt kiểu trượt
*Cutter(Non stop rotary type) - Dao cắt quay liên tục
*External Label Stocker - Khay đựng nhãn
*8MB Flash memory
*LAN interface 100 Base-TX/10 Base-T(TCP/IP Protocol) |
Phần mềm |
*BarTender Ultra Lite Plus
*Windows Drivers |
Kích thước |
*8.9"W x 11.8"H x 10.25"D(225mmW x 300mmH x 260mmD) |
Trọng lượng |
*12.5kg |
