| SPEED |
Up to 1131 mm/sec (44 in./sec) diagonal |
 |
| ACCELERATION |
Up to 3 g diagonal |
|
KNIFE
PRESSURE |
0-400 grams, in 5-gram increments |
|
| RESOLUTION |
0.025 mm, 0.1 mm selectable (Metric)
0.001 in., 0.005 in. selectable (English) |
|
| REPEATABILITY |
Within +/- 0.1 mm (0.004 in.) on plots:
up to 8 m (26 ft.) long on rolls up to 760 mm (30 in.) wide
up to 4 m (13 ft.) long on rolls over 760 mm (30 in.) wide |
|
TOOL
COMPATIBILITY |
Standard D-Series knife for vinyl, reflective and fluorescent films
Thick material D-Series knife for sandblast resist and other thick films
Pen for plotting on paper
Pounce tool (optional) for pouncing on paper |
|
MEDIA
WIDTH |
Roll: 115 - 670 mm / sheet 115 - 670 mm
1) >595mm (61cm)
2) >490mm (50cm)
3) >395mm (40cm)
4) >290mm (A3)
5) >210mm (A4)
6) >115mm (scrap) *Sensor disabled
|
|
MEDIA
LENGTH |
50 m (164 ft.) maximum |
|
| MEDIA THICKNESS |
Up to 0.25 mm (0.01 in.) with standard knife
up to 0.8 mm (0.03 in.) with thick material knife |
|
|
| MEMORY |
16 MB |
|
| INTERFACE |
USB 1.1 and Serial RS-232C |
|
| LANGUAGES |
Summa DM/PL, HP-GL or HP-GL2
(with selectable origin HP7475 and HP 7580/7585) |
|
POWER
REQUIREMENTS |
100-120 / 220-240 Vac, 48-62 Hz, 85 VA maximum |
|
OPERATING
ENVIRONMENT |
15° to 35° Celsius (59° to 95° Fahrenheit) |
|
ASSEMBLED
DIMENSIONS |
30 x 100 x 35 cm (11.8 x 39.4 x 13.8 in.)
112 x 100 x 68 cm (44.1 x 39.4 x 26.8 in.) with optional stand |
|
SHIPPING
WEIGHT |
23 kg (51 Lbs.)
35 kg (77 Lbs.) with optional stand |
|
STANDARD
ACCESSORIES |
OPOS optical positioning sensor
Long-plot media feed rollers
Media roll-end flanges (2)
Drag-knife blade holder
Standard blades (2)
Fibre-tip pen (1)
USB cable
Summa Cutter Control software
WinPlot cutting software
MacSign Cut cutting software
Coupy® slitter and blades (2)
User guide (PDF file on CD)
Quick Start guide
Power cable |
|
OPTIONAL
ACCESSORIES |
Deluxe stand with media basket
Thick material blade holder
Thick material blades (5-pack)
D-Series pounce kit |
