| TYPE |
120 cm (48 in.) drag-knife, friction feed |
 |
| SPEED |
Up to 1000 mm/sec. (40 in./sec.) axial;
Up to 1414 mm/sec. (56 in./sec) diagonal |
|
| ACCELERATION |
Up to 4 g axial;
Up to 5.5 g diagonal |
|
KNIFE
PRESSURE |
0-400 grams, in 5-gram increments |
|
ADDRESSABLE
RESOLUTION |
0.025 mm, 0.1 mm selectable (Metric);
0.001 in., 0.005 in. selectable (English) |
|
| REPEATABILITY |
Vinyl =/< 76 cm (30 in.):
Within +/- 0.1 mm (0.004 in.) on plots up to 12 m (40 ft.) long;
Vinyl > 76 cm (30 in.):
Within +/- 0.1 mm (0.004 in.) on plots up to 4 m (13 ft.) long; |
|
TOOL
COMPATIBILITY |
Standard knife for vinyl, reflective and fluorescent films;
Thick material knife for sandblast resist and other thick films;
Pen for plotting on paper;
Pounce tool for pouncing on paper |
|
MEDIA
WIDTHS |
11.5 to 130 cm (4.5 to 51 in.) |
|
MEDIA
LENGTH |
50 m (164 ft.) maximum |
|
MEDIA
THICKNESS |
Up to 0.25 mm (0.01 in.) with standard knife;
Up to 0.8 mm (0.03 in.) with thick material knife |
|
| CUTTING AREA |
120 cm x 50 m (47.2 in. x 164 ft.) maximum |
|
| MEMORY |
16 MB |
|
| INTERFACE |
USB 1.1 and Serial RS-232C |
|
DISPLAY
LANGUAGES |
English; French; German; Dutch; Italian; Spanish; Polish |
|
CUTTER
LANGUAGES |
Summa DM/PL, HP-GL or HP-GL2 (with selectable origin ; HP7475 and HP 7580/7585) |
|
POWER
REQUIREMENTS |
100-240 Vac, 48-62 Hz, 85 VA maximum |
|
OPERATING
ENVIRONMENT |
15° to 35° Celsius (59° to 95° Fahrenheit);
35 to 80% relative humidity (non-condensing) |
|
DIMENSIONS
(W x D x H) |
187 x 68 x 111 cm (73.6 x 26.8 x 43.7 in.) |
|
SHIPPING
WEIGHT |
86 kg |
|
OTHER
FEATURES |
OPOS™ X contour-cutting alignment system
Stand with adjustable front and rear media baskets
Media supply rollers with media end flanges
Media cutoff system
Automatic interface selection
Selectable origin
Variable knife-tip offset (0-1 mm / 0-0.04")
8 user-definable configurations
Autoload feature
Adjustable pinch roller pressure
Dual protection strips (cut and pounce)
Overcut feature (for easier weeding)
Flex-cut feature (for cutting completely through the media) OptiCut™ and TurboCut™ performance enhancement modes
Vector look-ahead
Curve and arc smoothing
Diagnostic routines |
|
ACCESSORIES
INCLUDED |
2 standard knife blades
Standard blade holder
Fiber tip pen
Power cord
Serial interface cable (PC) and USB Cable (PC/Mac)
Quick start guide (English, French, German, Italian, Spanish and Dutch)
User's manual and drivers on CD-ROM
Summa Cutter Control™ software (for controling cutter settings)
WinPlot™ (PC) and MacSign Cut (Mac) cutting programs |
