Gear box
|
173
|
Screw diameter
|
10mm
|
Cylinder outer diameter
|
120mm
|
L/D
|
1:20
|
Screw and cylinder material
|
38CR
|
Motor screen changing die head
|
Mould diameter:220mm
|
Main motor
|
22kw(frequency conversion controlled, frequency conversion from: Shanghai, brand: Anda)
|
Heat cutting motor die head
|
1.5kw(frequency conversion controlled, frequency conversion from: Shanghai, brand: Anda)
|
Heating way
|
Electricity heating, it uses the high frequency ceramics
|
Cooling way
|
blower
|
Automatic temperature controlled box
|
6areas controlled:the model of digital display
|
Feeding blower
|
1.5kw(strong blower)
|
Material conveying pipe
|
5m(rubber pipes)
|
Material storehouse
|
1 piece,iron sheet material
|
Capacity
|
about 100kg/h
|
