General
|
Aspect Ratio
|
16:9 (Native) 4:3
|
Brightness (ANSI Lumens)
|
1500 ANSI Lumens
|
Contrast Ratio
|
16000:1
|
Display Type
|
0.74" Polysilicon TFT LCD x 3
|
Resolution (Native / Max)
|
HD (1920 x 1080)
|
Video Compatibility
|
PAL, PAL-M, PAL-N, PAL 60, SECAM, NTSC, HDTV (720p, 1080i,
1080p), EDTV (480p, 576p)
|
Projection Lens
|
F = 1.9 ~ 3.2
f = 22.4 ~ 44.8mm
|
Size
|
Dimensions (WxHxD)
|
18.1in. x 5.1in. x 11.8in.
(45.97cm x 12.95cm x 29.97cm)
|
Weight
|
15.9 lbs. (7.21 kg)
|
Connectivity
|
Inputs
|
3 x HDMi
1 x D-Sub 15pin
2 x Component
1 x S-Video
1 x RCA Video
|
Outputs
|
1 x D-Sub 15pin
|
Control
|
1 x RS-232C
|
Operation
|
Power Supply
|
100 ~ 240 V / 50 ~ 60 Hz
|
Power Consumption
|
240W (Normal)
0.8W (Stanbdy)
|
Operating Temperature
|
32°F ~ 104°F (0°C ~ 40°C)
|
Operating Humidity
|
20 ~ 80% (Non-Condensing)
|
Projection Lens
|
Lamp Type
|
165W UHM
|
Lamp Life
|
2000 hrs
|
Lens Shift
|
Vertical: +/- 100%
Horizontal: +/- 40%
|
Projection Distance
|
3.3ft. ~ 39.4ft. (1.01m ~ 12.01m)
|
Projection Mode
|
Front, Ceiling
|
Projection Screen Size (Diagonal)
|
40in. ~ 200in. (101.6cm ~ 508cm)
|
Throw Ratio
|
1.37 ~ 2.73:1
|
Optical Zoom
|
2.0:1
|
Vertical Keystone Correction
|
+/- 30 Degrees
|
Brightness Uniformity
|
85%
|
Other
|
H-Sync
Range
|
30 ~ 70 kHz
|
V-Sync
Range
|
50 ~ 87 Hz
|
In The Box
|
Items
|
Power Cord
Remote Control
|
