Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Mode No. 9116V ITEM DESCRIPTION VIDEO SIGNAL Television System NTSC PAL VIDEO FEATURES Live (Real time display) 480f/s display with 16ch 400f/s display with 16ch Zoom 2 times digital Sequence Sequence display in Full size Display Format 1 screen

	Mode No.	9116V
	ITEM	DESCRIPTION
VIDEO SIGNAL	Television System	NTSC		PAL
VIDEO FEATURES	Live (Real time display)	480f/s display with 16ch		400f/s display with 16ch
	Zoom	2 times digital
	Sequence	Sequence display in Full size
	Display Format	1 screen(full), Quad pages split, 9 split, 16 split
	Camera Video enhance	Brightness, Contrast control for each Camera
	VGA out control	Brightness, Contrast, saturation
AUDIO FEATURES	G.723	4ch Input / 1ch Output
RECORD	Recording Speed	480 IPS	400 IPS
	Recording resolution	360x240 (NTSC) 360x288 (PAL)
	Codec	Mpeg-4
	Recording	Timer, Motion, Alarm, Manual individually set
	Pre, Post record	1~10 sec
	Material	2 HDD(Auto over write)
SEARCH	Manual, Timer ,Motion, Alarm, Each Camera, All Camera	Fast x128 , Slow, Forward, Revise, Image by image
BACKUP	DVD r/w, CD r/w, HDD, Stick memory, Network	Each Camera, ALL Camera, Time range
Recorded Data Rock	Data protect in overwrite HDD	Time range, Back up	Time range, Back up
USER INTERFACE	GUI	RGB 24bit full color
	Operating interface	Mouse, Keypad, IR remote controller, Network
	Jog shuttle	Jog shuttle in front panel
	Operating Help	Instant on screen display
Language	Multi language	English, Chinese, Japanese, Russian, Korean
NETWORK	Ethernet 10/100M Auto	TCP/IP, DHCP, DDNS, MNS server
PC Program	Remote Viewer	Same as DVR monitoring and control (Mouse or Key button)
	CMS	Same time 32 site connect and control, 640 site grouping
	PC Player	DVD, CD, external HDD, USB memory, pc HDD (Replay, AVI convert, Copy, Print)
Communication	2way Audio communication	PC and DVR
USB	USB 2.0	DVD r/w, CD r/w, HDD, Stick memory
SERIAL	RS232 / RS422 / RS485	16 camera Pan/Tilt, Remote control
ALARM	Alarm Inputs	16 Inputs
	Alarm Outputs	4 Relay Output(3A max)
	Alarm latch up	1 ~ 10 sec
	Buzzer Out	On/Off
HDD	SATA	2 HDD
POWER	Input Voltage	AC 110VA/ 220VA(Selectable) 50~60Hz
	Power consumption	Approx. 80W
CONNECTORS	Video Inputs	16 BNC
	Video Outputs	16 BNC(Looping)
	Audio Inputs	16 RCA
	Audio Output	1 RCA
	Composite monitor Outputs (Monitor, VCR)	2 BNC
	VGA monitor Output	15pin HDSUB
	Alarm In/Out	26pin HDSUB
	RS485 /RS422 /RS232	9pin DSUB
	Ethernet	RJ45
	USB	3 USB ports
MECHANICAL	Dimension(cm/cm)	44(W)x39(D)x9(H)
	Weight	Approx. 13Kg
ENVIRONMENT	Operating Temperature	0 ~ 60 deg C
	Humidity	10 ~ 90%
