Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Channel&Compression 4CH H.264 8CH H.264 16CH H.264 Video format 1.0V p-p/75Ω, BNC×4 1.0V p-p/75Ω,BNC×8 1.0Vp-p/75Ω, BNC×16 Video input 1.0V p-p/75Ω, BNC×1, VGA Video output 1.0V p-p/75Ω BNCX1 Display resolution D1:720×576 (PAL) / D1:720×480 (NTSC)

Channel&Compression	4CH H.264		8CH H.264			16CH H.264
Video format	1.0V p-p/75Ω, BNC×4		1.0V p-p/75Ω,BNC×8			1.0Vp-p/75Ω, BNC×16
Video input	1.0V p-p/75Ω, BNC×1, VGA
Video output	1.0V p-p/75Ω BNCX1
Display resolution	D1:720×576 (PAL) / D1:720×480 (NTSC)
Record/network resolution	CIF:352×288 (PAL) / CIF:352×240 (NTSC)
Display frame rate	4×25FPS (PAL) ,4×30 FPS (NTSC)	8×25 FPS (PAL) ,8×30 FPS (NTSC)		16×25 FPS (PAL) ,16×30 FPS (NTSC)
Record frame rate	CIF:100 FPS (PAL) / CIF:120 FPS (NTSC)	CIF:200 FPS (PAL) / CIF:240 FPS (NTSC)		CIF:400 FPS (PAL) / CIF:480 FPS FPS (NTSC)
Audio input	8k8bit, AV×4 (4CH record )	8k8bit, AV×4 (8CH record )		8k8bit, AV×4 (16CH record )
Audio output	8k8bit, AV×1 (4CH record )	8k8bit, AV×1 (8CH record )		8k8bit, AV×1 (8CH record )
Alerm method	Sensor alarm,motion detection alarm,video loss alarm,diskfull pre-alarm
Record mode	Manual/Sensor/Timer/Motion detection
Simplex/multiplex	Multiplex
Network port	RJ45
PTZ	RS485
USB port	High speed USB2.0 for mouse,backup and upgrade
Hard disk	Support One 1 Terabyte HDD and external HDD
Power supply	12V 4A
Power	Lower than 6W(without HDD)				Lower than 9W(without HDD)
Weight	About 3.1Kg with package
External Dimension(mm)	335mm(L)×250mm(W)×65mm(H)
Price RMB
