Model
|
GX-24
|
|
Driving method
|
Digital control servo motor
|
|
Cutting method
|
Media-moving method
|
|
Loadable material width
|
50 to 700 mm (2 to 27-1/2 in.)
|
|
Maximum cutting area
|
Width: 584 mm (22-15/16 in.)
Length: 24998 mm (984-1/8 in.)
|
|
Acceptable tool
|
Special blade for CAMM-1 series
|
|
Maximum cutting speed
|
500 mm/s (all directions)
|
|
Cutting speed
|
10 to 500 mm/s (all directions)
|
|
Blade force
|
30 to 250 gf
|
|
Mechanical resolution
|
0.0125 mm/step (0.000492 in./step)
|
|
Software resolution
|
0.025 mm/step (0.000984 in./step)
|
|
Distance accuracy *1
|
Error of less than ±0.2 % of distance traveled, or ±0.1
mm, whichever is greater
|
|
Repetition accuracy *1*2
|
±0.1 mm or less
|
|
Alignment accuracy for printing and cutting when loading
printed material *1*3
|
±1 mm or less for movement distance of 210 mm or less in
material-feed direction and movement distance of 170 mm or less in width
direction
(Excluding effects of printer and/or material)
|
|
Interface
|
USB interface (compliant with Universal Serial Bus
Specification Revision 1.1), Serial (RS-232C)
|
|
Replot memory
|
800 Kbyte
|
|
Instruction system
|
CAMM-GL III
|
|
Power supply
|
Dedicated AC adapter
Input: AC 100 to 240 V ±10 % 50/60 Hz 1.7 A
Output: DC 24 V, 2.8 A
|
|
Power consumption
|
Approx. 30 W (including AC adapter)
|
|
Acoustic noise level
|
During operation
|
70 dB (A) or less (according to ISO 7779)
|
|
During standby
|
40 dB (A) or less (according to ISO 7779)
|
|
Dimensions
|
855 (W) x 315 (D) x 240 (H) mm (33-11/16 (W) x 12-3/8 (D)
x 9-7/16 (H) in.)
|
|
Weight
|
16 kg (35 lb.)
|
|
Environment
|
Temperature: 5 to 40 °C (41 to 104 °F), humidity: 35 to 80
% (no condensation)
|
|
Included items
|
AC adapter, power cord, blade, blade holder, separating
knife, roller base, tweezers, test-use material, application tape, USB cable,
CD-ROM, user' manual
|
