PHYSICAL CHARACTERISTICS
|
|
Dimensions without stand:
|
5.51 in. H x 3.49 in. W x 2.96 in. D
(14 cm H x 8.86 cm W x 7.52 cm D)
|
|
Dimensions with stand:
|
6.13 in. H x 3.93 in. W x 3.93 in. D
(15.57 cm H x 9.98 cm W x 9.98 cm D)
|
|
Weight:
|
Scanner only: Scanner only: 9.9 oz./282 g
With stand: 12.2 oz./379 g
|
|
Power source:
|
Depending on host:
* Host power
* External power supply
|
|
Voltage1:
|
5.0 VDC ± 10%
|
|
Nominal current:
|
275 mA
|
|
Power:
|
1.4 watts
|
|
Mounting options:
|
Fixed-mount stand
|
|
Color:
|
Twilight Black
|
|
Performance Characteristics
|
|
Light Source:
|
650 nm visible laser diode
|
|
Yaw tolerance (typical) 2:
|
± 50°
|
|
Pitch tolerance (typical) 2:
|
± 50°
|
|
Roll tolerance (typical)2:
|
0 to 360°
|
|
Print contrast:
|
25% minimum reflective difference
|
|
Scan patterns:
|
Omni-directional, 20 interlocking lines
|
|
Scan rate:
|
1500 scans/second
|
|
Depth of field:
|
0 to 8.5 in. (0 to 21.6 cm) @ 13 mil (100% UPC/EAN)
|
|
Nominal working range:
|
5 mil: (38%) 1 to 2.5 in. (2.5 to 6.4 cm)
7.8 mil: (60%) 0 to 6 in. (0 to 15.2 cm)
10.4 mil: (80%) 0 to 7.5 in. (0 to 19 cm)
13 mil: (100%) 0 to 8.5 in. (0 to 21.6 cm)
|
|
Width of field:
|
1.6 in. (40 mm) @ face
6.42 in. (163 mm) @ 8.5 in
|
|
Minimum resolution:
|
5 mil
|
|
Decode capability:
|
UPC/EAN/JAN, UPC/EAN w/ Supplementals, UCC/EAN128, Code 128, ISBT 128, Code 39, Trioptic Code 39, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Code 93, Code 11, Codabar, MSI, RSS 14, RSS Limited, RSS Expanded
|
|
Interfaces supported:
|
USB, RS232, Keyboard Wedge and Wand
|
|
User Environment
|
|
Operating temperature:
|
32º to 104ºF (0º to 40º C)
|
|
Storage temperature:
|
-40º to 158ºF (-40º to 70ºC)
|
|
Humidity:
|
5% to 95% non-condensing
|
|
Ambient light immunity:
|
mmune to normal artificial indoor and natural outdoor (direct sunlight) lighting conditions. Fluorescent, incandescent, mercury vapor and sodium vapor: 450 ft-candles (4,844 lux) Sunlight: 8,000 ft-candles (86,111 lux)
|
|
Drop specifications:
|
Withstands repeated 4-ft. (1.2-m) drops to concrete
|
|
Regulatory
|
|
Electrical safety:
|
Certified to UL 1950, CSA C22.2 No. 950
|
|
Laser safety:
|
CDRH Class IIa Laser Product
IEC 60825 Class 1 Laser Product
Class IIa Laser Product – Avoid Long-Term Viewing of Direct Laser Light
|
|
EMC:
|
CISPR B, FCC B, EN60825
|
