◆Can be extended to 8 telephone alarm cards at most
◆Number of networked users : up to 10000
◆The host with independent receiving alarm function , each line with independent windows to display state information and capable of storing 50 user mainframe alarming records and 50 status records
◆Use professional modularization design , any line problem won’t effect other routes to work normally . Faults can be quickly judged and excluded
◆Audio output port , capable of output of monitoring signal of alarming prompt tone or sound at alarming site
◆Compatibility with C&K 、SHIKE、4+2 and Contract ID communication protocols
◆Built-in linked relay ,capable of linking other alarm receiving devices
◆The following functions are available by connecting the system with PC and using SHIKE center software : sound recording in hard disk , electronic map , wall-hanging map display, LED display , timing checkup , automatic printing , statement automatic generation and printing statistics inquiry
◆Can increase the image and message receiver module ,enrich variety ways of receiving alarm
◆Automatic testing and warning of telephone line failure
◆Full-system caller ID function to display the numbers of incoming calls
◆Built-in speaker , capable of output of monitoring signal of alarming prompt tone or sound at alarm site ,adjustable volume
Receiving Alarm communications
|
By PSTN dialing (receive alarm form 8 lines meanwhile at most)
|
Working current
|
Usual duty state﹤﹦80MA
Receiving alarm﹤﹦200MA
|
Alarm communication protocol
|
C&K , Contact ID , 4+2 , SHIKE
|
Applicable temperature
|
-10~55℃
|
Communication method with computer
|
RS-232 (Optical Coupler)
|
Applicable humidity
|
<90%
|
Display method
|
8-bit numerical indicator tube and LED status display
|
Power supply
|
AC220V±10%、50HZ
|
Alarm method
|
Built-in alarm horn sound , adjustable volume
|
Spare power supply
|
Optional
|
Setting method
|
Mainframe keypad input
|
installation style
|
Desktop
|
Receiving alarm response time
|
Can be adjusted
|
Material of casing
|
High-quality steel plate
|
Data memory for inquiry
|
50 records for alarm , 50 records for non-alarm events
|
Dimensions(L·W·H)
|
482×520×182mm
|
Alarm linked output
|
NO/NC、load: 1A 120VAC/24VDC
|
Weight(plus battery)
|
≤14kg
|
