Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

CPU32-bit secure CPU, ARM9, 180MHzMemoryHand Set: 8MB FLASH, 16MB SDRAMDisplay128×64 pixel LCD, LED backlight and Professional iconKeypad10 alphanumeric keys, 9 function keys, 1 power switch keyWhite LED backlightMagnetic Card ReaderCompliant with

CPU	32-bit secure CPU, ARM9, 180MHz
Memory	Hand Set: 8MB FLASH, 16MB SDRAM
Display	128×64 pixel LCD, LED backlight and Professional icon
Keypad	10 alphanumeric keys, 9 function keys, 1 power switch key White LED backlight
Magnetic Card Reader	Compliant with ISO7811, ISO7812; Track 1/2/3, bi-directional swipe
Smart Card Reader	1 user card(EMV2000), support SLE4442 / SLE4428 memory card
PSAM Slot	2 PSAM slots, compliant with ISO7816
Contactless Card Reader (Optional)	Supports Mifare classic, Mifare Ultra light, Mifare DESFire, ISO 14443 A & B, SONY FeliCa
Internal PINPad	Supports MK/SK, Fixed, DUKPT Supports dual and triple length TDES; Supports RSA
Communication	GPRS / CDMA / WiFi Support SSL v2/3 TLSv1
Printer	High speed thermal printer Easy-load style Speed: up to 28 lines/sec (84mm/sec) Paper width:58 +0/-1mm Paper roll outside diameter: 38mm Adjustable print gray, supports dual-layer thermal paper
Peripheral Port	2 RS-232 (up to 4), 5V @ 500mADC output
Power Supply	Input: 100 ~ 240VAC, 50Hz/60Hz; Output: 12VDC, 3A
Li-ion Battery	2150mAh, 7.4V, more than 40 hours standby time, supports 400 transactions
Working Environment	Temperature : 0 50 , Humidity : 10% 90%
Storage Environment	Temperature :-20 60 Humidity : 5% 95%
Dimensions	215mm × 89.5mm × 62.8mm (L×W×H)
Weight	566g
Certification	CCC, CE, FCC, UL, RoHS, PCI PED, EMV4.2 Level1&2,PBOC2.0
