Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Đặc điểm nổi bậtContentSpecificationsBasicCPU & ChipsetIntel®Celeron® J1800 Dual Core(2.58 GHz 1M Cache) Intel®Celeron® J1900 Quad Core (2.0GHz, 2M Cache) System on chip (SoC)Memory2GB DDR3 1333MHz, SoDIMM (Up to 8GB)Storage2.5", SATA-III SSD 64GB↑

Đặc điểm nổi bật

	Content	Specifications
Basic	CPU & Chipset	Intel®Celeron® J1800 Dual Core(2.58 GHz 1M Cache) Intel®Celeron® J1900 Quad Core (2.0GHz, 2M Cache) System on chip (SoC)
	Memory	2GB DDR3 1333MHz, SoDIMM (Up to 8GB)
	Storage	2.5", SATA-III SSD 64GB↑ Support IDE/ACHI mode
	Display	15", 1024 X 768, 24Bit, Luminance : 300 cd/㎡, Backlight : LED
	Dual Display port	1EA HDMI, Intel® HD Graphics
	LAN	1EA (Realtek RTL8111F PCIe GbE Controller)
	Serial	5EA (DSUB-9p x 2EA / RJ-45 x 3EA) Support Powered COM1,2 (select by BIOS)
	Parallel(LPT)	-
	PS/2	-
	USB	4EA(I/O)(USB3.0&2.0), 2EA (Rear) (USB 2.0)
	Audio	Line-Out
	Speaker	1 EA (1W) (Internal Speaker)
	Cooler & FAN	Fanless
	Power Adaptor	60[W] Adaptor, Input AC 100~240V/50~60HZ, DC 12V/5A
	Dimension(mm)	384(W) x 347(H) x 225(D) (Normal Angle, With Stand)
	Weight	4.8kg
	OS supported	POSReady7 / Windows 10 IoT / Linux / Android
Optional	OS	POSReady7 / Windows 10 IoT
	Storage	2.5", SATA-III HDD 500
	Touch Panel	15"Bezel type, 5-Wire Resistive 15”Bezelless type, Projective Capacitive Touch
	Dual Display	9.7", TFT-LCD, 1024x768, LED panel (Touch)
	Customer Display	VFD type, 20 Characters X 2 Lines, Serial(RS-232C)
	Secure Card Reader	EMV1, EMV2, MSR ISO Track1/2/3
	Wall Mount	Fixed Type / Swivel Type (75x75, 100x100mm VESA)
	Case Color	White & Black (Bezel type only) Black Black & White (Bezelless type only)
