Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

ProcessorHand Set: 32-bit secure CPU, ARM9, 180MHzBase Set: 32-bit CPU, ARM9, 200MHzMemoryHand Set: 8MB FLASH, 16MB SDRAMBase Set: 128MB FLASH, 16MB SDRAMKeypad10 alphanumeric keys, 9 function keysBack light (optional)Magnetic Card ReaderCompliant

Processor	Hand Set: 32-bit secure CPU, ARM9, 180MHz Base Set: 32-bit CPU, ARM9, 200MHz
Memory	Hand Set: 8MB FLASH, 16MB SDRAM Base Set: 128MB FLASH, 16MB SDRAM
Keypad	10 alphanumeric keys, 9 function keys Back light (optional)
Magnetic Card Reader	Compliant with ISO7811, ISO7812; Track 1/2/3, bi-directional swipe
Smart Card Reader	1 user card(EMV2000), support SLE4442 / SLE4428 memory card
PSAM Slot	2 PSAM slots, compliant with ISO7816
Contactless Card Reader (Optional)	Supports Mifare classic, Mifare Ultra light, Mifare DESFire, ISO 14443 A & B, SONY FeliCa
Remote Download	Supports New TMS or FTP remote download
Printer	High speed thermal printer Easy-load style Speed: up to 28 lines/sec (84mm/sec) Paper width:58 +0/-1mm Paper roll outside diameter: 38mm Adjustable print gray, supports dual-layer thermal paper
Internal TCP/IP(Optional)	10Base-T/100Base-T, supports SSLv2/3 TLSv1
Power Supply	Input: 100 ~ 240VAC, 50Hz/60Hz; Output: 12VDC, 3A
Working Environment	Temperature : 0 50 , Humidity : 10% 90%
Storage Environment	Temperature :-20 60 Humidity : 5% 95%
Dimensions	256mm × 104mm × 81mm (L×W×H)
Weight	800g
Certification	PCI PED online / offline, EMV4.2 Level1&2,PBOC2.0
