Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

ModelRP-3112BRP-3115BProcessorVIA Eden™ (ULV) Processor 1.6 GHzSystem Memory1 GB Standard, Maximum 1 GB (1 x 200-pin DDR2)Power Supply150W (12V/12.5A) External Power AdaptorStorage Device1 x 2.5” SATA HDD1 x CF Card (Optional)ConstructionAluminum Die

Model	RP-3112B	RP-3115B
Processor	VIA Eden™ (ULV) Processor 1.6 GHz
System Memory	1 GB Standard, Maximum 1 GB (1 x 200-pin DDR2)
Power Supply	150W (12V/12.5A) External Power Adaptor
Storage Device	1 x 2.5” SATA HDD
	1 x CF Card (Optional)
Construction	Aluminum Die-casting, Plexi-Glass Acrylic (Front Bezel)
Housing Color	Black / Silver
Touch LCD Display
Size / Resolution	12” TFT LCD / 800 x 600	15” TFT LCD / 1024 x 768
Brightness	400 cd/m²	250 / 350 cd/m²
Touch Screen	5-Wire Resistive Touch

I/O Ports
Serial Port	3 x External : COM1 & COM2, COM4 (RJ45)
USB Port	4 x External (2 in Front, 2 in Rear)
Printer Port	1 x Bi-directional Parallel Port
Cash Drawer Port	1 x 12V RJ11 (Single/Dual)
Keyboard / Mouse	1 x PS/2
LAN Port	1 x RJ45 10/100
Video Port	1 x VGA
Audio Port	1 x Line-out
DC Output	1 x 12V for 2nd Display

OS Supported
Windows	Windows XP, Windows XPE, POSReady 2009, Windows 7
Linux	Per Request

Physical Dimensions
Dimensions (WxHxD)	325 x 345 x 235 mm	375 x 390 x 235 mm

Environment
EMI / Safety	CE, FCC Class A
Operating Temperature	0˚C ~ 40˚C (32˚F ~ 104˚F)
Storage Temperature	-10˚C ~ 50˚C (14˚F ~ 122˚F)
Relative Humidity	10% ~ 90% (non-condensing)

Optional Peripherals
Magnetic Stripe Card Reader	MCR Single/Dual/Triple Track
2-in-1 / 3-in-1 Module	MCR+i-Button/MCR+RFID/MCR+Fingerprint/MCR+Smartcard+i-Button
2nd Display	8.4”/12.1”/15” Pole-type LCD Display (Touch Screen Optional)
Customer Display	VFD / LCM Pole-type Customer Display
Wireless LAN	Integrated 802.11 b/g/n Wireless Module
