Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

FunctionJIVA-8315N JIVA-8315N-iProcessorIntel T3100 Dual Core 1.9 GHz / 1 MB Cache CPU or Intel Core 2 Duo P8400 2.26 GHz / 3 MB Cache CPU or Intel Core 2 Duo T9400 2.53 GHz / 6 MB Cache CPUSystem MemoryDDR2 667/800 MHz, SO-DIMM x 2, max 4 GB,

Function	JIVA-8315N	JIVA-8315N-i
Processor	Intel T3100 Dual Core 1.9 GHz / 1 MB Cache CPU or Intel Core 2 Duo P8400 2.26 GHz / 3 MB Cache CPU or Intel Core 2 Duo T9400 2.53 GHz / 6 MB Cache CPU
System Memory	DDR2 667/800 MHz, SO-DIMM x 2, max 4 GB, default 1 GB
Storage Device	2.5” SATA HDD or SSD Kit (optional)
Power Supply	12V DC power adaptor, 80W
Audio	Line out / Mic in, optional 2W speaker
OS support	Win 7 / Win XP Pro / POSReady 7 / POSReady 2009 / Linux
Display
LCD	15” TFT LCD, 1024 x 768 resolution
Touch Function	Resistive, 5-wire, USB Interface	IR touch
Brightness Control	By software control
Tilt Adjustment	From 15° to 75°
Connectivity
LAN Port	10 / 100 / 1000 Mb
Parallel Port	Yes
Serial Port	DB9x4, with 5V support on COM1/COM2/COM3/COM4
PS/2 Keyboard	Yes
PS/2 Mouse	Yes
UPS Port	Yes, optional battery
Standard USB Port	5
Proprietary USB Port	1 for side mounted option
VGA Port	D-SUB 15 Pin, with 12V power for Posiflex LCD Monitor
CR Port	1, control 2 CR
Physical Dimension
Dimension (W x D x H in mm)	376 x 321 x 372
Weight (N. W. in kg)	10.3
Environment
Operation Condition	0°C - 40°C, 20%RH - 90%RH
Storage Condition	(-20°C) - 70°C, 10%RH - 90%RH
Options
PD-302	2 x 20 LCD, rear mount
PD-305	2 x 20 LCD, rear top mount
PD-306 / PD-306U	2 x 20 LCD, default 200 mm pole
PD-2602 / PD-2602U	2 x 20 VFD, default 200 mm pole
PD-76 x 2	240 x 64 dot Graphics LCD, 200 mm pole
SSD	8 GB minimum
MSR	SD-100, 2 or 3 tracks and JIS-II(optional) or smart card reader(optional) or iBotton(Optional), SD-200, 2 or 3 tracks and JIS-II(optional) or Finger Print sensor(optional) SD-810, 2 or 3 tracks and JIS-II(optional) or RFID (optional) or WiFi (Optional)
UPS Battery	2300 mAh / 12V
2nd LCD Display	12” LM-6101B, 15” LM-6501B / LM-8015B
2nd HDD	Yes
RAID Function	Support RAID 1(Disk Mirroring)
HT-022	COM5 / COM6 Adaptor Board ,with 5V support
BC-100U	Barcode Card Reader, USB interface
KP-100	Mini footprint design security keyboard, 40 keys (24 programmable keys and ten keys configuration) attachment, Smart card reader(optional), MSR: 2 or 3 tracks or JIS-II (optional)
