Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Image device 1/3“ SONY SUPER HAD , HQ1 Pixels NTSC : 752(H) x 582(V) ； PAL : 768(H) x 494(V) Horizontal Resolution 550 TV line Minimum Illumination 0.8 LUX / F1.2 Auto Electronic Shutter AES ON : NTSC:1/60s~1/100,000s, PAL:1/50s~1/110,000s ; OFF :

Image device 1/3“ SONY SUPER HAD , HQ1 Pixels NTSC : 752(H) x 582(V) ； PAL : 768(H) x 494(V) Horizontal Resolution 550 TV line Minimum Illumination 0.8 LUX / F1.2 Auto Electronic Shutter AES ON : NTSC:1/60s~1/100,000s, PAL:1/50s~1/110,000s ; OFF : NTSC:1/60s, PAL:1/50s Auto Iris Control Video-Drive Lens & DC-Drive Lens both supported Gamma Characteristic 0.45 Lens Mount C or CS mount adjustable Gain Control Automatically White Balance Auto White Balance(AWB) Back Light Compensation ON/OFF Switch-able Synchronous System Inter line Synchronization Lens Auto Scanning System PAL : 625 Lines , 50Field/S ; NTSC : 525 Lines , 60Fied/S Video Output 1Vp-p75 ohms, Negative Electronics Shutter PAL : 1/50~1/100,000 sec S/N Ratio More than 48dB (AGC off) Power Input DC 12V Operation Temperature -10°C ~ +50°C RH95%Max Storage Temperature -20°C ~ +60°C RH95%Max
