Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Pick Up Element 1/3" SONY SUPER HAD D.S.P. Sony Digital Signal Processor Picture Element NTSC: 510(H) x 492(V) ; PAL: 500(H) x 582(V) Horizontal Frequency NTSC: 15.734 KHz. ; PAL: 15.625 KHz. Vertical Frequency NTSC: 59.94 Hz. ; PAL: 50 Hz.

Pick Up Element 1/3" SONY SUPER HAD D.S.P. Sony Digital Signal Processor Picture Element NTSC: 510(H) x 492(V) ; PAL: 500(H) x 582(V) Horizontal Frequency NTSC: 15.734 KHz. ; PAL: 15.625 KHz. Vertical Frequency NTSC: 59.94 Hz. ; PAL: 50 Hz. Synchronization Internal , Negative Sync. Scanning System 2 : 1 Interlace Resolution Horizontal 420 TV Lines Low-light Sensitivity 0.06 Lux @F1.6 S/N Ratio More than 48 dB (AGC OFF) Gain Control Automatic Gain Control (AGC) Electronic Shutter Auto: 1/60 (50) sec. ~ 1/100,000 sec. ; Off: 1/60 (50) sec. White Balance Auto White Balance (2500K ~ 9500K) Gamma Characteristic r = 0.45 Lens Built-in 4.0mm CS-mount Lens Video Output 1.0 Vp-p Composite Video Output ; 75 Ohm Operating Temperature - 10 ~ + 50 degree C / RH 85% or Less Power Consumption Max. 1.7 W Power Supply DC 12V Dimension 138.5mm (Φ) x 104mm (H) Weight 450 grams Operation Lens 6.0mm, 8.0mm, 12.0mm or 16.0mm CS-mount lens
