Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Pick Up Element 1/3" SONY SUPER HAD, IP66 Picture Element NTSC: 510(H) x 492(V) ; PAL: 500(H) x 582(V) Horizontal Frequency NTSC: 15.734 KHz. ; PAL: 15.625 KHz. Vertical Frequency NTSC: 59.94 Hz. ; PAL: 50 Hz. Synchronization Internal, Negative Sync.

Pick Up Element 1/3" SONY SUPER HAD, IP66 Picture Element NTSC: 510(H) x 492(V) ; PAL: 500(H) x 582(V) Horizontal Frequency NTSC: 15.734 KHz. ; PAL: 15.625 KHz. Vertical Frequency NTSC: 59.94 Hz. ; PAL: 50 Hz. Synchronization Internal, Negative Sync. Scanning System 2 : 1 Interlace Resolution Horizontal 420 TV Lines Low-light Sensitivity 0.1 Lux @F2.0 / 0 Lux with IR-LED S/N Ratio More than 48 dB (AGC OFF) Gain Control Automatic Gain Control (AGC) Electronic Shutter Auto: 1/60 (50) sec. ~ 1/100,000 sec. White Balance Auto White Balance (2500 K ~ 9500 K) Lens Built-in 6.0mm/F2.0 Board Lens (Optional with 4.3 / 8.0 / 12.0mm Board Lens) Video Output 1.0 Vp-p Composite Video Output ; 75 Ohm Infra Red Luminary 28 Units of IR-LED ; Life: 6,000 Hours Wavelength 850 nm Beam Spread Angle 35 degree Illuminating Distance Max. 20~25 Meter Illuminator Active Limit Under 5 Lux (with Linear Control) Power Supply DC 12V +/- 10% Operating Temperature - 10 ~ + 50 degree C / RH 85% or Less Waterproof Standard IP 66 Waterproof Standard Dimension 60mm (Dia.) x 120mm (L) Weight 600 Grams
