Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

TECHNICAL DATESICM 60 TDWorking widthmm1450Cleaning capacity up tom2/h17400Operating rangeh Solution tank capacityl340Recovery tank capacityl340Waste tank capacity (cylindrical brushes version)l19TECHNICAL DATESICM 60 TDMechanical drive (front/rear)

TECHNICAL DATES		ICM 60 TD
Working width	mm	1450
Cleaning capacity up to	m2/h	17400
Operating range	h
Solution tank capacity	l	340
Recovery tank capacity	l	340
Waste tank capacity (cylindrical brushes version)	l	19
TECHNICAL DATES		ICM 60 TD
Mechanical drive (front/rear)
Traction (motoroue/diff./hydrost.)		N°2 hydraulic motor
Forward speed	km/h	0/12
Max. slope	%	13
Water lift		1700
Brush pressure	kg	0/120
Noise level	DB	91
Turning radius	mm	3020
ELETTRIC DATES		ICM 60 TD
Power	V	36
Vacuum motor	W	2x 850
Brush motor	W	OR 80 C
Traction motor	W	OP 160 C
Feeding		36V - 400A/h
MOTORIZATION		ICM 60 TD
Feeding (diesel/fuel/gas)
Mark/model of the engine		Kubota
N° cylinders		3
Power/rounds		14kW/3600rpm
Cooling		H2O
WEIGHT AND DIMENSIONS		ICM 60 TD
Length	mm	2230
Width	mm	1550
Height	mm	1500
Number of brushes and diameter	mm	3x Ø460
Squeegee width	mm	1650
