Tủ Ấm CO2 Phòng Thí Nghiệm Kolner KNX-50

Tủ Ấm CO2 Phòng Thí Nghiệm Kolner KNX-50

Model

KNX-50

Application

used for drying, baking, and thermal treatment

Heating and air circulation type

6-side heating wire+breeze circulation system+air jacket design

Performance

Temperature range

RT+5～55℃

Temperature resolution

0.1℃

Temperature fluctuation

±0.1℃

Temperature uniformity

±0.35℃

CO2 concentration range

0～20%

CO2 concentration fluctuation

±0.5%

chamber humidity

≥90%RH

Structure

chamber material

SUS304 Cu mirror stainless steel

shell material

spraying cold rolled steel

thermal insulation material

PU

heating device

Nickel-chromium alloy heating wire with silica gel cover

CO2 intake

φ8mm

CO2 filter

DUF imported

shelf material

SUS304 mirror stainless steel

rated power

0.18kw

Controller

Temperature control

PID

CO2 concentration control

PID

Temperature setting

press the 6 keys slightly

Temperature display

4 digital tube display

CO2 concentration display

3 digital tube display

timer

0～9999 minutes(with timed wait)

operation function

running with data set and time set, and automatic shut-down based on setting

temperature sensor

Pt100

CO2 concentration sensor

imported

water level sensor

imported

additional function

deviation adjustment, menu buttons lock, power outage compensation, power outage memory

Safety device

over-temperature alarm, menu lock, and CO2 concentration abnormity alarm, and warning water level alarm.

Specification

working size (W*D*Hmm)

350*380*380

exterior size (W*D*Hmm)

465*480*580

packing size (W*D*Hmm)

515*530*630

working capacity

50L

load bearing of shelf

15kg

shelf bracket groove

9

height between shelves

35mm

Power source( 50/60Hz)/Rated current

AC220V/0.8A

NW/GW

46/55kg
