Trung tâm gia công dọc NV-1280

Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Machine SpecificationItemUnitNV-1280TravelX axis travelmm(in)1,280(50.3")Y axis travelmm(in)650(25.5")Z axis travelmm(in)630(24.8")Distance from spindle nose to table surfacemm(in)100~730(3.9" ~ 28.7")Distance from spindle center to columnmm(in)722

Machine Specification

Item	Unit	NV-1280
Travel
X axis travel	mm(in)	1,280(50.3")
Y axis travel	mm(in)	650(25.5")
Z axis travel	mm(in)	630(24.8")
Distance from spindle nose to table surface	mm(in)	100~730(3.9" ~ 28.7")
Distance from spindle center to column	mm(in)	722(28.4")
Table
Table dimension	mm(in)	1,380 × 650(54.3" x 25.5")
Max. loading weight	kg(lb)	1,200(2,645)
T-slots (W x No. x P)	mm(in)	18 x 5 x 100(0.7" x 5 x 3.9")
Spindle
Spindle speed(OPT)	rpm	10,000(12,000 / 15,000)
Spindle motor	kW(HP)	11 / 15(20HP)
Spindle taper	type	7/24 taper No.40
Automatic Tool Changer
ATC type	type	Arm type
Tool shank	type	BT-40
Pull stud	type	P-40T (45°)
Tool storage capacity(OPT)	pcs.	24(30 / 32 / 40)
Max. tool diameter	mm(in)	Ø80(Ø3.1")
Max. tool diameter (Adjacent empty)	mm(in)	Ø150(Ø5.9")
Max. tool length	mm(in)	250(9.8")
Max. tool weight	kg(lb)	7(15)
Tool change time (Tool to Tool)	sec.	2.5
Tool change time (Chip to Chip)	sec.	7
Feedrate
Rapid feedrate (X / Y / Z)	m(in)/min	36 / 36 / 24 (1,417.3 / 1,417.3 / 994.8)
Cutting feedrate	mm(in)/min	10,000(393.7)
Other
Floor plan (W × D)	mm(in)	3,750 × 2,500(147" x 98")
Machine weight	kg(lb)	8,500(18,739)
Max. machine hight	mm(in)	2,800(110")
Air source	kg/cm2(PSI)	6~8(85~113)
Power capacity	KVA	25
