Thiết bị kiểm tra bánh răng TTi-120h Tokyo technical

Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

THÔNG TIN SẢN PHẨMStandard accessories.: - Feeler (0.5 / 0.7 / 1.0 / 1.25 / 1.5 / 2.0) 1bộ - Test Gear 1set - Work Driver & Fork 1set - Wrench

THÔNG TIN SẢN PHẨM

Standard accessories.: - Feeler (0.5 / 0.7 / 1.0 / 1.25 / 1.5 / 2.0) 1bộ

- Test Gear 1set

- Work Driver & Fork 1set

- Wrench 1set
- Operation Manual 1pc
- Inspection Report 1set
- Mandrel 1set
- Level Mount 1set
- Feeler Stand 1pc

Optional accessories: Worm Detector
- Floating Table
- Special Center
- Long Vertical Support (350mm)
- Internal Holder
- Special Feeler
Peripheral Equipment

Thông số kỹ thuật

Test item	Spur/ Helical gear, Internal gear: Profile, Lead, Pitch Electronic generating DDC loop system
Measuring system	Electronic generating DDC loop system /NDG Measuring System
Measuring module	m0.2〜4.0
Base circle dia.	TTi-120E / Φ120mm （outer diameter Φ130mm） TTi-150E / Φ150mm （outer diameter Φ160mm）
Helix angle	±65°（90°）
Gear width	200mm Max
Shaft length	10〜260mm
Max gear weight	20kg Max
Drive system	onstant-current drive
Machine Weight	650kg
Power supply	AC100V, 50/60Hz, 15A
Measurement accuracy0.1μｍ
