Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Test Voltage From 500Vdc to 10KVdc adjustable in 500 V steps Preset Buttons 1kV, 2.5kV, 5kV, 10kV Measuring Range 800K Ohm ~ 500G Ohm (auto-ranging) Accuracy +/- 5% +/- 2 digits Optput Power Limit 1W Voltage Regulation Selected voltage +20%-5% of

Test Voltage From 500Vdc to 10KVdc adjustable in 500 V steps
Preset Buttons 1kV, 2.5kV, 5kV, 10kV
Measuring Range 800K Ohm ~ 500G Ohm (auto-ranging)
Accuracy +/- 5% +/- 2 digits
Optput Power Limit 1W
Voltage Regulation Selected voltage +20%-5% of nominal vlaue unless current limited. Meaning that if ouotput current is too high, the voltage will be lowered automatically
Weight Appox. 3.6kg
Dimensions 330(L) x 260(W) x 160(D)mm
Power Source 8 x 1.5V Alkaline batteries
Accessories Color coded flexible silicone test leads
Instruction manual
Batteries
Các tính năng chính
- Smart microprocessor controlled.
- 2 x 16 characters, large, High Contrast, Intelligent L.C.D. Module.
- 20 Insulation test voltages. 500V, 1kV, 1.5kV, 2kV, 2.5kV, 3kV, 3.5kV, 4kV, 4.5kV, 5kV, 5.5kV, 6kV, 6.5kV, 7kV, 7.5kV, 8kV, 8.5kV, 9kV, 9.5kV, 10kV
- Calculate Dielectric Absorption Ratio (DAR) automatically.
- Calculate Polarization Index (PI) automatically.
- Insulation resistance Auto-Ranging on all ranges.
- Ener-Save (tm).
- Bargraph indicates test voltage. Rise and decay can be observed.
- Warning of external voltage presence (>500Vac or Vdc).
- Overload protection.
- Low battery indicator (real time battery Voltage Measurement).
- Measure insulation time duration of the test.
- Low battery consumption.
- Better than 10% accuracy on all ranges.
- Auto-off.
