| Product specifications |
| Infrared temperature range |
| 566: |
-40 °C to 650 °C (-40 °F to 1202 °F) |
| 568: |
-40 °C to 800 °C (-40 °F to 1472 °F) |
|
| Infrared accuracy |
| |
< 0 °C (32 °F): ± (1.0 °C (± 2.0 °F) + 0.1°/1 °C or °F);
> 0 °C (32 °F): ± 1 % or ± 1.0 °C (± 2.0 °F), whichever is greater |
|
| Display resolution |
|
| Infrared spectral response |
|
| Infrared response time |
|
| Thermocouple Type-K input temperature range |
| |
-270 °C to 1372 °C (-454 °F to 2501 °F) |
|
| Thermocouple Type-K input accuracy |
| -270°C to -40°C: |
± (1 °C + 0.2 °/1 °C) (-454 °F to -40 °F: ± (2 °F + 0.2 °/1 °F)) |
| -40°C to 1372°C: |
± 1 % or 1 °C (-40 °F to 2501 °F: ± 1 % or 2 °F), whichever is greater |
|
| D:S (distance to measurement spot size) |
|
| Laser sighting |
| |
Single-point laser < 1 mw output Class 2 (II) operation, 630 nm to 670 nm |
|
| Minimum spot size |
|
| Emissivity adjustment |
| |
By built-in table of common materials or digitally adjustable from 0.10 to 1.00 by 0.01 |
|
| Data storage with Date/Time stamp |
| 566: |
20 points |
| 568: |
99 points |
|
| PC Interface and cable |
| 566: |
None |
| 568: |
USB 2.0 with FlukeView® Forms software |
|
| Hi/Low alarms |
| |
Audible and two-color visual |
|
| Min/Max/Avg/Dif |
|
| Display |
| |
Dot matrix 98 x 96 pixels with function menus |
|
| Backlight |
| |
Two levels, normal and extra bright for darker environments |
|
| Trigger lock |
|
| Switchable Celsius and Fahrenheit |
|
| Power |
| 566: |
2 AA/LR6 Batteries |
| 568: |
2 AA/LR6 Batteries and USB when used with a PC |
|
| Battery life |
| If used continuously: |
laser and backlight on,12 hours; laser and backlight off, 100 hours |
|
| Operating temperature |
| |
0 °C to 50 °C (32 °F to 122 °F) |
|
| Storage temperature |
| |
-20 °C to 60 °C (-40 °F to 140 °F) |
|
| Bead thermocouple Type-K range |
| |
-40 °C to 260 °C (-40 °F to 500 °F) |
|
| Bead thermocouple Type-K accuracy |
| |
± 1.1 °C (2.0 °F) from 0 °C to 260 °C (32 °F to 500 °F), typically within 1.1 °C (2.0 °F) from -40 °C to 0 °C (-40 °F to 32 °F) |
|
