Máy tiện CNC Takang TNC-06N

Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

ModelMô tảTNC-06NTNC-08NCapacitySwing over bed400 mm400 mmSwing over saddle160 mm200 mmDistance between centers–400 mmCutting diameter / lengthØ 130 / 160 mmØ 200 / 480 mmHydraulic chuck6″8″Bar capacityØ 42 mmØ 52 mmBed width220 mm320 mmBed slant

Model	Mô tả	TNC-06N	TNC-08N
Capacity	Swing over bed	400 mm	400 mm
	Swing over saddle	160 mm	200 mm
	Distance between centers	–	400 mm
	Cutting diameter / length	Ø 130 / 160 mm	Ø 200 / 480 mm
	Hydraulic chuck	6″	8″
	Bar capacity	Ø 42 mm	Ø 52 mm
	Bed width	220 mm	320 mm
	Bed slant angle	25°	20°
Spindle	Spindle nose	A2-5	A2-6
	Spindle hole	50 mm	60 mm
	Spindle speed	100-6000 rpm	100-4000 rpm
	Spindle motor	5. 5 kw / 7. 5HP (servo)	7. 5 kw / 10HP (servo)
	Spindle OD diameter	Ø 85 mm	Ø 100 mm
Turret (Option)	Turret type	Hydraulic	Hydraulic
	Tool station	8	8
	Tool holder size	Ø 25 mm, □ 20 mm	Ø3 2 mm, □ 25 mm
Travel	X Travel	230 mm	320 mm
	Y Travel	300 mm	560 mm
	Rapid travel	16 M / Min.	12 M / Min.
Tailstock	Tailstock travel	–	360 mm
	Quill taper	–	MT4
	Tailstock diameter	–	Ø 53 mm
	Quill travel	–	100 mm
Motor	Servo motor (X)	1HP (HA 40)	1HP (HA 40)
	Servo motor (Z)	1HP (HA 40)	2HP (HA 80)
	Coolant pump	1/4 HP	1/4 HP
	Hydraulic motor	1 HP	1 HP
Weight	Kgs	1780	3000
Machine Size	L x W x H mm	2440 x 1260 x 1830	3200 x 1860 x 1850
