Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Testing Range:(8～650)HBWTest Force:612.9N(62.5Kgf), 980N(100Kgf), 1226N(125Kgf), 1839N(187.5Kgf), 2452N(250Kgf), 4900N(500Kgf), 7355N(750Kgf), 9800N(1000Kgf), 14700N(1500Kgf), 29400N(3000kgf)Accuracy of Displayed Hardness ValueHardnessRange(HBW)Max

Testing Range:(8～650)HBW
Test Force:612.9N(62.5Kgf), 980N(100Kgf), 1226N(125Kgf), 1839N(187.5Kgf), 2452N(250Kgf), 4900N(500Kgf), 7355N(750Kgf), 9800N(1000Kgf), 14700N(1500Kgf), 29400N(3000kgf)
Accuracy of Displayed Hardness Value
HardnessRange(HBW)	Max tolerance％	Repetition％
≤ 125	± 3	≤ 3.5
125＜HBW≤225	± 2.5	≤ 3.0
＞ 225	± 2.0	≤ 2.5
Max Height of the speciment: 225mm
Max Distance from the indenter center to the instrument panel: 135mm
Magnification of the microscope: 20X
Min Reading Grade of the Drum wheel of the microscope: 0.00125mm
Power supply and Voltage: AC220V/50-60Hz
Main Accessories
Tables: large, small, and v-shaped each
Hard Alloyed Steel Balls Indenters: Φ2.5mm, Φ5mm and Φ10mm each.
One Microscope: 20X
Two Standard Hardness Blocks.
