Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Technical data: Loads:3000kgf (29400N), 1500Kgf (14700N), 1000Kgf (9800N), 750Kgf(7355N), 500Kgf (4900N), 250Kgf (2452N), 187.5Kgf (1839N), 125Kgf (1226N), 100Kgf (980N), 62.5Kgf(612.9N) Load dwell duration: 2s～99s, can be set and stored Tungsten

Technical data:
Loads:3000kgf (29400N), 1500Kgf (14700N), 1000Kgf (9800N), 750Kgf(7355N),
500Kgf (4900N), 250Kgf (2452N), 187.5Kgf (1839N), 125Kgf (1226N),
100Kgf (980N), 62.5Kgf(612.9N)
Load dwell duration: 2s～99s, can be set and stored
Tungsten Carbide Ball indenter: 10mm,
Measuring range: 3.18HBW~658HBW
Magnification of the microscope: 20X
Resolution capability of the microscope: 0.005mm
Accuracy of Brinell Hardness Value:
Hardness Range(HBW)   Error (％)   Repeatability(％)
≤ 125   ± 3.0   ≤3.0
125＜HBW≤225   ± 2.5   ≤2.5
＞ 225    ±2.0    ≤2.0
Max measurable height: 230 mm
Max measurable depth: 140 mm
Dimensions: 530mm×260mm×750mm
Power supply: 220/110 V, 50/60 Hz, 4A
Weight: 120kg
Standard blocks: 125-350HBW10/3000, 125-350HBW10/1000
Hãng sản xuất: HUATEC
Xuất xứ: Trung quốc
