Máy quét rác công nghiệp Fiorentini S 48 D

Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Máy quét rác công nghiệp Fiorentini S48TECHNICAL DATESS 48 BS 48 DS 48 DKWorking widthmm-with 2 side brushesmm176017601760-with 1 side brushmm145014501450-only central brushmm120012001200Cleaning capacity up tom2/h130501710017100Operating rangeh3

Máy quét rác công nghiệp Fiorentini S48

TECHNICAL DATES		S 48 B	S 48 D	S 48 DK

Working width	mm
-with 2 side brushes	mm	1760	1760	1760
-with 1 side brush	mm	1450	1450	1450
-only central brush	mm	1200	1200	1200
Cleaning capacity up to	m2/h	13050	17100	17100
Operating range	h	3.5
Waste tank dischange (m/idr)
Waste tank capacity	l
Max. discharging height	mm	1450	1450	1450
TECHNICAL DATES		S 48 B	S 48 D	S 48 DK

Sweeping type (front/rear)		front	front	front
Mechanical drive (front/rear)
Traction (motoroue/diff./hydrost.)		@NOTE7@	@NOTE7@	@NOTE7@
Forward speed	km/h	0/9	0/11.8	0/11.8
Filter type		/	/	/
Max. slope	%		13	13
Filtering surface		16.8 / 10	16.8 / 10	16.8 / 10
Central cylindrical brush speed rotation	rmp	388	388	388
Side brush speed rotation	rmp	87	87	87
Noise level	DB	80	82	82
Turning radius	mm	2435	2435	2435
Vibrations (hand/arm)		Aw=2	Aw=2.05	Aw=2.05
Central brush motor
Side brush motor
ELETTRIC DATES		S 48 B	S 48 D	S 48 DK

Power	V	48
Vacuum motor	W	800
Feeding		2x 24V - 625A/h
MOTORIZATION		S 48 B	S 48 D	S 48 DK

Feeding (diesel/fuel/gas)
Mark/model of the engine			Lombardini LDW1404	Kubota
N° cylinders			4	4
Power/rounds			37cv x 3600rpm	33cv x 3000rpm
Cooling
WEIGHT AND DIMENSIONS		S 48 B	S 48 D	S 48 DK

Length	mm
-with 2 side brushes	mm	2360	2360	2360
-only central brush	mm	2270	2270	2270
Width	mm	1515	1515	1515
Height	mm	1510	1510	1510
Ø roll central brush	mm	Ø 380	Ø 380	Ø 380
Roll central brush length	mm	1200	1200	1200
Ø side brush	mm	Ø 560	Ø 560	Ø 560
Weight of the batteries (approx.)	kg
Weight of the machine	kg	1500	1504	1504
