Máy Quét Mã Vạch OPI3201

Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Đặc điểm của máy Máy có thể đọc được Code 1D và code 2D : PDF 417, Micro PDF 417. Máy bao gồm chân đế giúp máy quét ở chế độ tự động. 2D Imager Optics2D Light source Aiming laser diode, illumination LEDs2D Scan method CMOS area sensor, SXGA (1.3

Đặc điểm của máy

Máy có thể đọc được Code 1D và code 2D : PDF 417, Micro PDF 417. Máy bao gồm chân đế giúp máy quét ở chế độ tự động.

2D Imager Optics
2D Light source Aiming laser diode, illumination LEDs
2D Scan method CMOS area sensor, SXGA (1.3 million pixels), gray scale
2D Scan rate Up to 80 fps (excl. focusing)
2D Trigger mode Manual, multiple read, auto-trigger, stand detection
2D Image format Windows Bitmap, JPEG, TIFF
2D Gradulation 256, 16, 2
2D Image output mode 4 resolutions (full, 1/2, 1/3, 1/4), 2 ranges (horizontal, vertical)

Thông số kỹ thuật của máy

Operating indicators
Visual	1 LED (red/green/orange)
Non-visual	Buzzer
Operating keys
Entry options	1 scan key
Communication
RS232	DB9 PTF connector with external power supply
Keyboard Wedge	MiniDIN6 F/M connector
USB	Ver. 1.1, HID/VCP, USB-A connector
Power
Voltage requirement	6V ± 5% (Keyboard Wedge), 6V (min. 4.5, max. 6.5V) (RS232)
Current consumption	Max. 350mA (typical use), max 85 mA (standby)
2D Imager Optics
2D Light source	Aiming laser diode, illumination LEDs
2D Scan method	CMOS area sensor, SXGA (1.3 million pixels), gray scale
2D Scan rate	Up to 80 fps (excl. focusing)
2D Trigger mode	Manual, multiple read, auto-trigger, stand detection
2D Image format	Windows Bitmap, JPEG, TIFF
2D Gradulation	256, 16, 2
2D Image output mode	4 resolutions (full, 1/2, 1/3, 1/4), 2 ranges (horizontal, vertical)
2D Reading pitch angle	-40 to 0°, 0 to +40°
2D Reading skew angle	-50 to 0°, 0 to +50°
2D Reading tilt angle	360°
2D Min. Resolution at PCS 0.9	0.127 mm / 5 mil, 0.169 mm / 7 mil, at Code39 / QR Code and Data Matrix
2D Min. PCS value	0.45/0.3
2D Field of view	Horizontal 40º, Vertical 23º
2D Depth of field	at Code 39: 15 - 55 mm / 0.59 - 2.17 in (0.127 mm / 5 mil), 15 - 200 mm / 0.59 - 7.87 in (0.254 mm / 10 mil), 90 - 870 mm / 3.54 - 34.25 in (1.0 mm / 39 mil), at QR Code: 15 - 170 mm / 0.59 - 6.69 in (0.339 mm / 13 mil)
Supported Symbologies
Barcode (1D)	JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/ Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
Postal code	Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, POSTNET
2D code	Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code
Durability
Temperature in operation	-5 to 50 °C / -23 to 122 °F
Temperature in storage	-20 to 60 °C / -4 to 140 °F
Humidity in operation	5 - 85% (non-condensing)
Humidity in storage	5 - 80% (non-condensing)
Ambient light immunity	Fluorescent 10,000 lx max, Direct sun 100,000 lx max, Incandescent 10,000 lx max
Drop test	1.5 m / 5 ft drop onto concrete surface
Vibration test	10 - 100 Hz with 2G for 1 hour
Protection rate	IP 42
Physical
Dimensions (w x h x d)	56 x 137 x 112 mm / 2.20 x 5.39 x 4.41 in
Weight body	Ca. 80 g / 2.8 oz (excl. cable)
Case	ABS, Black or White
Regulatory & Safety
Product compliance	CE, FCC, VCCI, RoHS, IEC 62471-1, IEC 60825-1 Class 1, IEC 60950-1
