Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Measuring Ranges Resolution 0 - 100% LEL * 0 - 100% Volume Gas * 0 - 25% Oxygen (O2) 0 - 100ppm Hydrogen Sulphide (H2S) 0 - 20% Carbon Dioxide (CO2) * 0 - 1000 ppm Carbon Monoxide (CO) ( * Infrared Detection) LEL Vol Gas O2 H2S CO2 CO 0 - 100% 0 -

Measuring Ranges	Resolution
0 - 100% LEL * 0 - 100% Volume Gas * 0 - 25% Oxygen (O2) 0 - 100ppm Hydrogen Sulphide (H2S) 0 - 20% Carbon Dioxide (CO2) * 0 - 1000 ppm Carbon Monoxide (CO) ( * Infrared Detection)	LEL Vol Gas O2 H2S CO2 CO	0 - 100% 0 - 100% 0 - 21% 21-25% 0 - 100ppm 0 - 5% 5 - 20% 0 - 1000 ppm	1% 1% 0.1% 1% 1ppm 0.1% 0.5% 1ppm
Certification	Environment
ATEX MED Download Product Datasheet for details.	Temperature Limits: -20Deg.C to +50Deg.C (-4Deg.F to +122Deg.F) Humidity: 0 to 100% R.H.
Alarms	Sampling System
Highly intensity red flashing LEDs Sounder in excess of 80dB(A), @300mm (12in.)	Integral pump with pressure sensor for rapid flow fail detection. Sample path protection using hydrophobic filter and automatic pump switch-off.
Physical Properties	Power Supply
Dimensions : 100 (H) x 180 (W) x 95 (D) mm 3.9 (H) x 7.1 (W) x 3.7 (D) in. Weight : 1.7 kg (3.75lbs.) with two alkaline batteries Moulded polypropylene case protected to IP54	2 Alkaline (approved LR20 'D' Size) or 2 Rechargeable Cells (approved LR20 'D' Size) Battery Life : 2 x Alkaline 20 Hrs 2 x Rechargeable
