Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Rated frequency (Hz)50 60Rated voltage(V)230 120/240Rated current (A)12.2 23.3/11.7Rated speed(r/min)3600Rated output (kVA)2.8Max. output (kVA)3.0DC output12V-5.0APhase numberSingleCurrent circuit breakerN/AStructural typeSilentFuel capacity

Rated frequency (Hz)	50 60
Rated voltage(V)	230 120/240
Rated current (A)	12.2 23.3/11.7
Rated speed(r/min)	3600
Rated output (kVA)	2.8
Max. output (kVA)	3.0
DC output	12V-5.0A
Phase number	Single
Current circuit breaker	N/A
Structural type	Silent
Fuel capacity£¨L£©	13
Set fuel consumption£¨g/kW.h£©	500
Continuous running time (hr) (rated output)	6.7
Noise level (zero load--full load) dB (A)/7m	63-67
Overall dimension(L¡ÁW¡ÁH)£¨mm)	684¡Á440¡Á505
Net weight£¨kg£©	57
Starting system	Recoil starter&Electric starter
Fuel type	Automotive unlead gasoline
Lube oil type	CD grade or SAE10W30, 15W40
Engine model	KG205GETi
Engine type	Single cylinder, 4-stroke, air-cooled, OHV, gasoline engine
Bore¡ÁStroke	68¡Á54
Displacement(ml)	196
Compression ratio	8.5¡Ă1
Rated power[kW(Hp)/(r/min)	4.0/3600
Ignition system	T.C.I
Spark plug	WR7DC
Lowest fuel consumption£¨g/kW.h£©	395
