Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Rated frequency(Hz) 50 60Rated voltage(V) 230 230/115Rated current(A) 2022.6/45.2Rated output power(kW) 4.65.2Rated rotation speed(rpm) 3000 3600DC output 12V 8.3APower factor(cos) 1.0Phase number Single phaseNoise level[dB(A)@7m] 74~77Overall

Rated frequency(Hz)		50 60
Rated voltage(V)		230 230/115
Rated current(A)		2022.6/45.2
Rated output power(kW)		4.65.2
Rated rotation speed(rpm)		3000 3600
DC output		12V 8.3A
Power factor(cos)		1.0
Phase number		Single phase
Noise level[dB(A)@7m]		74~77
Overall dimension(LWH)[mm(in)]		720X492X650(28.35X19.37X25.59)
Dry weight[kg(ibs.)]		100(220)
Structure type		Open-frame type
Coupling mode		Transmission shaft rigid couping
Engine model		KM186FAE
Engine type		Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacement[ml(cu.in)]		418(25.51)
Compression ratio		19:1
Rated power[kW(Hp)/rpm]		5.9(8.02)/3000,6.5(8.84)/3600
Starting system		recoilstarter
Rotation direction(View from flywheel)		Clockwise
Fuel		0# (summer),-10# (winter) light diesel oil

Rated frequency(Hz)		50 60
Rated voltage(V)		230 230/115
Rated current(A)		20 22.6/45.2
Rated output power(kW)		4.6 5.2
Rated rotation speed(rpm)		3000 3600
DC output		12V 8.3A
Power factor(cos)		1.0
Phase number		Single phase
Noise level[dB(A)@7m]		74~77
Overall dimension(LWH)[mm(in)]		720X492X650(28.35X19.37X25.59)
Dry weight[kg(ibs.)]		100(220)
Structure type		Open-frame type
Coupling mode		Transmission shaft rigid couping
Engine model		KM186FAE
Engine type		Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacement[ml(cu.in)]		418(25.51)
Compression ratio		19:1
Rated power[kW(Hp)/rpm]		5.9(8.02)/3000,6.5(8.84)/3600
Starting system		recoil starter
Rotation direction(View from flywheel)		Clockwise
Fuel		0# (summer),-10# (winter) light diesel oil
