Máy nén khí trục vít trực tiếp DG30A

Machine Model

DG30A

Displacement (M3 / min)
/ Discharge pressure
(Bar)

4.9 / 7

4.7 / 8

4.3/10

4.0/12

Displacement (CFM)
/ Discharge pressure
(PSI)

173/101.5

166/116

152/145

141/174

Gas temperature ()

Ambient temperature +10 ~ 15

Temperature shutdown protection ()

110

Gas oil content (ppm)

3

Suction conditions

Ambient temperature45, Atmospheric pressure, relative humidity less than 80%

Transmission

Gear / Direct drive

Cooling

Air

Starting method

Y-△

Input Power
(V) / (PH) / (Hz)

380/3/50

Input power
(HP / kW)

40/30

Motor speed
(Rpm)

2940

Population size pipeline

G1

Dimensions (mm)

1376x856x1085

Unit Weight (kg)
