SPECIFICATION / MODELS

PSGO

60150AHR

75150AHR

75220AHR

75300AHR

General Capacity

Max. travel (cross x longitudinal)

660x1650mm

810x1650mm

810x2350mm

810x3150mm

Spindle center height from table

700(950)mm

Max height from table top to bottom of standard wheel

Grinding surface of table

600x1500mm

750x1500mm

750x2200mm

750x3000mm

Longitudinal Movement

Hydraulic table speed

1-25m/min

Cross Movement

Intermittent cross feed-approx.(Electro-mechanical)

0.1-15mm/feed

Continuous cross feed-approx.(Electro-mechanical)

2000mm/min(50Hz),2400mm/min(60Hz)

Hand feed per revolution

5mm

Hand feed per division

0.02mm

Vertical Downfeed

Rapid traverse approx.(option)

240mm/min

Hand feed per revolution

0.25mm

Hand feed per division

0.0025mm

Grinding Wheel

Dimension(O.D x W x I.D)

355x50x127mm

Spindle speed(50/60Hz)

1500/1800 r.p.m.

Motor

Spindle motor

7.5(11)kW/10(15)HP

Hydraulic motor

5.6kW/7.5HP

Weight

Net weight

9350kg

11000kg

12500kg

14400kg

Gross weight

10800kg

12300kg

14000kg

16000kg

Packing Size

Dimension (L x W x H) (m)

5.4x2.27x2.8

6.92x2.27x2.8

7.47x2.27x2.8
