Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Specification : Ave. Output Power3W/6WLaser Wavelength1064nmPeak power30KW/3KHz, 45KW/3KHz (Repetition Rate)Laser Frequency Range1000Hz~50KHzMarking ModeVector、Raster、DrillingMarking StyleStationaryNo.of Object256 Objects (Max)Character TypeNumerical

Specification :

Ave. Output Power	3W/6W
Laser Wavelength	1064nm
Peak power	30KW/3KHz, 45KW/3KHz (Repetition Rate)
Laser Frequency Range	1000Hz~50KHz
Marking Mode	Vector、Raster、Drilling
Marking Style	Stationary
No.of Object	256 Objects (Max)
Character Type	Numerical Value; Letter
Character Height	0.3~100mm (Adjustable by 0.2mm)
Character Width	Depend on character scale or field length settings
Working Area	110x110mm, 175x175mm
Nominal Focal Length	160mm (110x110mm), 254mm (175x175mm)
Scanning Speed	12m/sec
Marking Speed	2.5m/sec
Precision	±0.05mm
Resolution	5um
Power	1Ø/220VAC, 5A (1Ø/110VAC, 10A), 50/60Hz, 1KVA
Input	Run/Stop
Output	Laser Ready/Laser Busy
Interface	Ethernet and USB port
Weight	Laser Head 12kg, controller 50kg
Dimension(laser Head)	765mm(L)x187mm(W)x166mm(H)
Dimension(Controller)	420mm(L)x360mm(W)x660mm(H)
Standard Configuration :
Pilot Laser,	Emergency Stop for Laser
6.4" TFT Touch Screen,	RAM:128MB
Safety Shutter,	HDD: 2.5",20GB
Iuput/output Terminal Block,	HMI Based on Windows CE Operating System
Software :
True Type Font Transfer
Customer Font Edit,
