Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Model WS1530 X.Y axis motion 1500mm (X)x 3000mm (Y) Z axis motion 170mm Table size(X/Y) 1600mm (X)x 3540mm (Y) Drive System X, Y axis : Rack and Pinion / Z axis : Ball Screw Max.Moving Speed 15M/min Max.Engraving Speed 12M/min Max.Feeding Height

Model	WS1530
X.Y axis motion	1500mm (X)x 3000mm (Y)
Z axis motion	170mm
Table size(X/Y)	1600mm (X)x 3540mm (Y)
Drive System	X, Y axis : Rack and Pinion / Z axis : Ball Screw
Max.Moving Speed	15M/min
Max.Engraving Speed	12M/min
Max.Feeding Height	180mm
Repeatability	0.05mm
Driving System		AC Servo motor
Resolution	0.00727mm
Controller	VDS III (DSP 160MHz)
File Type	HP-GL, G-Code
Computer OS	Windows98/2000/XP
Power Supply	3 Phase 380V/50Hz
Spindle	3500W Air cooling
Spindle rotary speed	0 to 18000 rpm
External Dimension	/ mm (W)x / mm (D)x / mm (H)
Weight	/ kgs
Operating Temperature and humidity	5 to 35 °C / 35 to 70% (non-condensing
