Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Measurement AccuracyVoltage DC30.000 V0.02%+ 2 counts (upper display)10.000 V0.02%+ 2 counts (lower display)90.00 mV0.02%+ 2 counts-10.00 mV to 75.00 mV0.025 % + 1 count (via TC connector)Current DC24.000 mA:0.02%+ 2 countsResistance0.0 to 400.0 Ω0

Measurement Accuracy
Voltage DC
30.000 V	0.02%+ 2 counts (upper display)
10.000 V	0.02%+ 2 counts (lower display)
90.00 mV	0.02%+ 2 counts
-10.00 mV to 75.00 mV	0.025 % + 1 count (via TC connector)
Current DC
24.000 mA:	0.02%+ 2 counts
Resistance
0.0 to 400.0 Ω	0.1Ω (4-wire), 0.15Ω (2- and 3-wire)
401 to 1500 Ω	0.5Ω (4-wire), 1Ω (2- and 3-wire)
500 to 3200 Ω	1Ω (4-wire), 1.5Ω (2- and 3-wire)
Frequency
2.0 to 1000.0 CPM	0.05 % + 1 count
1.0 to 1100.0 Hz	0.05 % + 1 count
1.00 to 10.00 kHz	0.05 % + 1 count
Sensitivity	1 V peak-to-peak-minimum
Pressure
Accuracy	from 0.025% of range using any of 8 intrinsic safe pressure modules. (for detailed specifications refer to pressure modules in options and accessories) Modules available for differential, gauge, vacuum, absolute, dual and high pressure.
