Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

VERTICAL Channels 2 / 4 2 / 4 2 / 4 Bandwidth DC ~ 60MHz (-3dB) DC ~ 100MHz (-3dB) DC ~ 200MHz (-3dB) Rise Time 5.8ns Approx. 3.5ns Approx. 1.75ns Approx. Sensitivity 2mV/div ~ 5V/div (1-2-5 increments) Accuracy ±(3% x |Readout|+0.05 div x Volts/div

VERTICAL
Channels	2 / 4	2 / 4	2 / 4
Bandwidth	DC ~ 60MHz (-3dB)	DC ~ 100MHz (-3dB)	DC ~ 200MHz (-3dB)
Rise Time	5.8ns Approx.	3.5ns Approx.	1.75ns Approx.
Sensitivity	2mV/div ~ 5V/div (1-2-5 increments)
Accuracy	±(3% x \|Readout\|+0.05 div x Volts/div+0.8mV)
Input Coupling	AC, DC & Ground
Input Impedance	1MΩ±2%, ~16pF
Polarity	Normal & Invert
Maximum Input	300V (DC+AC peak), CATII
Waveform Signal Process	+ , - , FFT
Offset Range	2mV/div ~ 20mV/div : ±0.5V 50mV/div ~ 200mV/div : ±5V 500mV/div ~ 2V/div : ±50V 5V/div : ±300V
Bandwidth Limit	20MHz (-3dB)
TRIGGER
Sources	CH1 , CH2 , CH3 , CH4 , Line
Modes	Auto-Level, Auto, Normal, Single, TV, Edge, Pulse Width
Coupling	AC , DC , LF rej. , HF rej. , Noise rej.
Sensitivity	DC ~ 25MHz : Approx. 0.5div or 5mV 25MHz ~ 200MHz : Approx. 1div or 10mV
