Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Total Power" 6750W Top heater: 1200W Bottom heater. 2nd heater 1200W,3rd IR heater 4200W power : AC220V±10% 50/60Hz Dimensions: 900*680*900 mm Positioning: V-groove, PCB support can be adjusted in any direction with external universal fixture

Total Power" 6750W
Top heater: 1200W
Bottom heater. 2nd heater 1200W,3rd IR heater 4200W
power : AC220V±10% 50/60Hz
Dimensions: 900*680*900 mm
Positioning: V-groove, PCB support can be adjusted in any direction with external universal fixture
Temperature control: K-type thermocouple (Closed Loop), heating independently, temperature precision within ±2 degree
PCB size: Max 390*450mm Min 125*20 mm
Electrical materials : Servo Drive( Panasonic)+Touch screen( Taiwan)+Panasonic PLC+Heating plate(Germany)
Camera magnification" 10x-100x
Optical system: Japanese original high-definition CCD color imaging system
BGA chip 1×1-80×80mm
Touch screen " 7.0?, Resolution 640X480, Panel Visa touch screen, external USB interface
External temperature sensor" four
Work Mode: Power drive
Placement Accuracy: X, Y axis and the R angle with micrometer adjust, accuracy within ± 0.01MM
Net weight: 85kg
