Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

THÔNG TIN SẢN PHẨMApplicable fibersSM MM DS NZDSFiber diameterCladding diameter:80-150μm; Coating diameter:100-1000μmFiber countSingleFiber cleaved length12-16mm (Coating diameter:250μm)Actual average splice loss0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0

THÔNG TIN SẢN PHẨM

Applicable fibers	SM MM DS NZDS
Fiber diameter	Cladding diameter:80-150μm; Coating diameter:100-1000μm
Fiber count	Single
Fiber cleaved length	12-16mm (Coating diameter:250μm)
Actual average splice loss	0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS)
Typical splicing time	Typical 9 sec (standard SM fiber)
Return loss	>60dB
Splicing mode	Auto Calibrate Normal Special
Fiber aligning method	Meticulous,Core,Clad,Manual
Splicing program	53 (templet), 40(user)
Tube heating program	9 (templet),24(user)
Tube typical heating time	Typical 30 sec
Protection sleeve length	60mm, 40mm
Storage of splice result	4000 results, 20 parameter per result
Fiber image magnification	300X (X or Y view),150X (X and Y view)
Battery capacity	Typical 150 cycles (splice/tube heat with inner Li-battery)
Monitor	5.7 inch color LCD monitor
Tension test	2N
Electrode life	2500
Terminal	USB
Power supply	AC 100-240V with AC adapter Inner Li-battery ( 7800 mAH)
Operating condition	0-5000m above sea level, -10-50°CMax wind velocity of 15m/s
Dimension	150mm(L)×150mm(W)×150mm(H)
Weight	2.55Kg excluding battery,3.05Kg including battery
