Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

DISPLAY • Phase rotation indication by both audio and indicator, checking if currents of three different rating are in proper phase. Phase open-circuit detection by indicator. FUNCTIONS • Detect the phase sequence (R-S-T) of 3-phase circuit •

DISPLAY
• Phase rotation indication by both audio and indicator, checking if currents of three different rating are in proper phase. Phase open-circuit detection by indicator.

FUNCTIONS
• Detect the phase sequence (R-S-T) of 3-phase circuit
• Electronic circuit configuration allows more specific function display
• Automated detection for low-battery capacity

SPECIFICATIONS
• Measuring range:

Frequency: 45-65HZ
Voltage: 50~500V (overload protection : 750V)
• Insulation voltage withstand protection: DC 6KV
ACCESSORIES
• User’s manual
• Carrying case
• 9V battery x 1pc
POWER SUPPLY
• Battery type: 9V NEDA 1604 IEC 6F22 JIS
006P x 1pc.
• Battery life: About 50 hours.
OPERATION CONDITION
• Operating temperature & humidity: 0°C~40°C, below 80% RH.
• Storage temperature & humidity: -10°C~60°C, below 70% RH.
DIMENSION
• Size: 105 x 62 x 24mm (L x W x H)
• Weight: About 206g (including battery)
DISPLAY
• Phase rotation indication by both audio and indicator, checking if currents
of three different rating are in proper phase. Phase open-circuit detection by indicator.
FUNCTIONS
• Detect the phase sequence (R-S-T) of 3-phase circuit
• Electronic circuit configuration allows more specific function display
• Automated detection for low-battery capacity
SPECIFICATIONS
• Measuring range:
Frequency: 45-65HZ
Voltage: 50~500V (overload protection : 750V)
• Insulation voltage withstand protection: DC 6KV
POWER SUPPLY
• Battery type: 9V NEDA 1604 IEC 6F22 JIS
006P x 1pc.
• Battery life: About 50 hours.
OPERATION CONDITION
• Operating temperature & humidity: 0°C~40°C, below 80% RH.
• Storage temperature & humidity: -10°C~60°C, below 70% RH.
DIMENSION
• Size: 105 x 62 x 24mm (L x W x H)
• Weight: About 206g (including battery).
