Máy đo oxi trong không khí PS1

Features

- On/Off capability

- Single gas monitors for H₂S, O₂, CO, SO₂

- Easy one button operation

- Displays real time value

- Datalogging as standard

- Includes fully programmable menu for alarms and latching/non-latching settings

- Alarms: audible, visual, vibrating, Time Weighted Average (TWA), Short TermExposure Limit (STEL), low battery and end of life

- Rugged stainless steel alligator clip

- Backlit LCD display

- IP67 - dust tight, and waterproof up to 1m/3ft

- Shipped with recyclable packaging

Applications

Petrochemical, Off-Shore, Chemical, Forklift Operations, Pulp and Paper, Cities, & Municipalities, Gas and Oil, Fire Departments, Boiler Room Monitoring. and more...

 Technical Specification

Measuring Ranges

H₂S 0 - 100ppm in 1ppm increments

O₂ 0 - 25% in 0.1% increments

CO 0 - 500ppm in 1ppm increments

(pending)

IECEx: Ex ia IIC T4 Ga

ATEX: Ex II 1G Ex ia IIC T4 Ga

UL913: Class I, Division 1, Groups A, B, C, D T4

MED: 96/98/EC As amended

CE

CSA: Class I, Division 1, Groups A, B, C, D T4 (pending)

Alarms

- Visual 360^o light bar, Vibrating, Audible alarm: 95dB

- User programmable, includes Time Weighted Average (TWA) and Short Term - Exposure Limit (STEL)

- Physical Properties

- Dimensions (Height x Width x Depth): 85 x 55 x 29 mm (3.4" x 2.2" x 1.16")

- Weight: 86g (3oz)

Environment

Temperature Limits: -20^oC to +50^oC (-4^oF to +122^oF)

Humidity: 0 - 98% RH (non-condensing)

Display: LCD backlit display

Power Supply: Li-SOCl₂ heavy duty 3.6V battery

Enclosure: High impact ABS poly blend
