Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Maximum measurement load50.000 N / 5.000 kgResolution10 N / 1 kgDynamometric cell cable lengthapprox. 3 mMeasurement uncertainty±0,05 % of the measurement valueGravitation mapmanual setting by means of a GPSMeasuring unitsN, g, lb, oz,

Maximum measurement load	50.000 N / 5.000 kg
Resolution	10 N / 1 kg
Dynamometric cell cable length	approx. 3 m
Measurement uncertainty	±0,05 % of the measurement value
Gravitation map	manual setting by means of a GPS
Measuring units	N, g, lb, oz, kg
Calibration	with F2 calibration weights
maximum overload	±20 % of the measurement range
Measurement rate	adjustable 10 values/s or 40 values/s
Measurement function	Traction and compression measurement / PEAK function (max, min, Hold) / measurement of limit values / real time measurements by means fo the software
Display	61 x 34 graphic display / simultaneous indication of relevant values such as date, time and current measurement value / automatic reverse display / setting of backlight, etc...
Menu	multilingual: German / English / Spanish
Internal memory	8 memory positions with 800 respective measurements
Record	manual - pressing one button automatic - 0,025 s - 99,9 s
Interface	RS-232, 9 poles
Printer connection	through the RS-232 interface
Software and data cable	with software for the control and valuation l
Operating conditions	-10 ºC ... +40 ºC
Power supply	internal NiMH accumulator ~230 V / 12 V mains adapter included Setting of the auto shut-off function
Accumulator duration	approx. 20 h (without backlight, approx. 45)
Dimensions	210 x 110 x 40 mm
Weight	550 g (without the dynamometric cell)
