Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Resolution 1N 0.1kgf 0.1lbf Unit kgf(gf), N, lbf(ozf)(Easy Reverse display function) Measuring mode Normal measuring & Peak measurings Display cycle 0.05,0.1,0.2,0.3,0.5,1 second Sampling Rate 1000 times/second Accuracy ±0.2% of R.C. ＋1/2 digit at 23

Resolution		1N 0.1kgf 0.1lbf
Unit		kgf(gf), N, lbf(ozf)(Easy Reverse display function)
Measuring mode		Normal measuring & Peak measurings
Display cycle		0.05,0.1,0.2,0.3,0.5,1 second
Sampling Rate		1000 times/second
Accuracy		±0.2% of R.C. ＋1/2 digit at 23℃
Influence of temperature		Span:±0.02%℃ Zero point drift/cancelled by tracting
Display		4 digit 12mm high LCD 1 display at tensile force (Reverse display selectable) Other displays 1."LOW BAT"(Battery is low)2."BAT"(Battery is being charged)3."OVR"(Overloaded)4."PEAK"(Peak hold mode)
Overload		200% of R.C.
Tracking		Selectable by ON/OFF
Output signals※1	RS-232C	See chart below
	Analog	±1V(±Max.load), 12bit D/A converter method, Output interval 140 times/sec.
	Overload	Open collector output (DC30V 5mA Max.)
Power		NiCd battery % AC adapter(DC9V 200mA), Measuring can be possible during charging."
Auto Power Off		In 10 minutes, Continuous operation is possible while powering by AC adapter
Temperature range		0～40℃
Dimensions		214mm(L)×82mm(W)×55mm(H)
Weight		900g
Accessories(Included)		Each of Flat head, Hook, Chisel, Vee, Cone, Extension Rod,Carring case, AC adapter, and Analog cable※
