Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

•Auto L.C.R. check •100 / 120 / 1k / 10k / 100k Hz test frequency •20,000 / 2,000 counts display •Backlit •Ls / Lp / Cs / Cp / Rs / Rp / DCR with D / Q / θ / ESR measurement •Relative mode •Series / Parallel modes • Components sorting function

•Auto L.C.R. check
•100 / 120 / 1k / 10k / 100k Hz test frequency
•20,000 / 2,000 counts display
•Backlit
•Ls / Lp / Cs / Cp / Rs / Rp / DCR with D / Q / θ / ESR measurement
•Relative mode
•Series / Parallel modes
• Components sorting function *Selectable tolerance ±0.25%, ±0.5%, ±1%, ±2%, ±5%, ±10%, ±20%, -20% +80%
• Low battery indication
• Optical IR to USB PC link (optional)

•Ω (parallel / series mode)	20Ω/200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ
•DCR	20Ω/200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ
•Capacitance (parallel / series mode)	200pF/2000pF/20nF/200nF/2000nF/20uF/200uF/2000uF/20mF
•Inductance (parallel / series mode)	20uH/200uH/2000uH/20mH/200mH/2000mH/20H/200H/2000H
•Low battery indicator	Yes
•Over range indicator	Yes
•LCD display	Dual display 20,000 / 2,000 counts
