Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Interchangeable probes. Multi-functioned type with memory, statistics, data transfer to PC Probe can be selected to meet optimal application of measurements Guide-messages of operation procedures on LCD screen. A large capacity of measurement memory

Interchangeable probes. Multi-functioned type with memory, statistics, data transfer to PC

Probe can be selected to meet optimal application of measurements
Guide-messages of operation procedures on LCD screen.
A large capacity of measurement memory 10,000 points
Measurements by simply calling registered calibrations.
Built-in setting method of high/low limit values and statistical functions
Availability of data transfer to PC by USB connections.

Applications

Coating / lining / plating
Insulating films such as anodic oxide coating (ALMITE)

Electro-magnetic / Eddy current

Substrate: Magnetic metal (iron, steel, etc.),
Non-magnetic metal (aluminum, copper, etc.)
Coating: Non-magnetic coating (painting, plating(excluding nickel), resin, etc.)

Specifications

Measuring range : Depending on optional probes
Display method : Graphic LCD
Calibrations : 2 points calibration type
Calibration memory : 10
Measurement memory : 10,000
Data transfer : USB
Power : Dry battery (R6P 1.5V)×2, Exclusive AC adaptor, Auto-power off
Temperature : 0～40℃(non-condensing)
Weight and dimensions : 72(W)×30(H)×156(D) mm, 200g
Accessories : Carrying case, Exclusive AC adaptor, USB cable, USB driver
Option : For ferrous substrate probe (Fe) For nonferrous substrate probe (NFe)
