Máy dập Aomate APA-60B

Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

SPECIFICATIONUnitAPA-15BAPA-25BAPA-35BAPA-45BAPA-60BModelVVHSVHVHVHCapacityTon1525354560Rated tonage pointmm13.21.63.23.21.63.21.642Speed changingS.P.M120-18060-140130-20060-12040-120110-18040-100110-15035-9080-120Stable SpeedS.P

SPECIFICATION
	Unit	APA-15B	APA-25B			APA-35B		APA-45B		APA-60B
Model		V	V	H	S	V	H	V	H	V	H
Capacity	Ton	15	25			35		45		60
Rated tonage point	mm	1	3.2	1.6	3.2	3.2	1.6	3.2	1.6	4	2
Speed changing	S.P.M	120-180	60-140	130-200	60-120	40-120	110-180	40-100	110-150	35-90	80-120
Stable Speed	S.P.M	130		110	110		85	75		65
Stroke	mm	60	70	30	80	70	40	80	50	120	60
Die height	mm	200	195	215	195	220	235	250	265	310	340
Slide adjustment	mm	50	50			55		60		75
Slide area	mm	300x230x50	300x230x50			360x250x50		400x300x60		500x360x70
Bolster area	mm	680x300x70	680x300x70		680x300x65	800x400x70		850x440x80		900x500x80
Shank hole	mm	Ø38.1	Ø38.1			Ø38.1		Ø38.1		Ø50
Main motor	kw.p	2.2×6	3.7×4			3.7×4		5.5×4		5.5×4
Slide adjust device	HP	Manual operation
Air pressure	kg/cm²	6	6			6		6		6
Presses precision		GB/JIS1class
Presses dimension	mm	1236x820x1920	1280x850x2200			1380x900x2400		1600x950x2500		1600x1000x2800
Presses weight	ton	1.8	2.1			3		3.8		5.6
Die cushion capacity	ton	–	–			2.3		2.3		3.6
Stroke	mm	–	–			50		50		70
Die cushion effective area	mm²	–	–			300×230		300×230		350×300
