Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Saw Motor power 3,0 kW (2,2 | 3,7 kW) Motor speeds 2 865/min.(3 438/min.[60Hz]) Max. saw blade diameter with scoring unit Ø 315 mm Spindle diameter 30 mm (5/8" | 1") Speed of main saw blade spindle 4 400/min. Max. depth of cut with scoring unit 100

Saw
Motor power	3,0 kW (2,2 \| 3,7 kW)
Motor speeds	2 865/min.(3 438/min.[60Hz])
Max. saw blade diameter with scoring unit	Ø 315 mm
Spindle diameter	30 mm (5/8" \| 1")
Speed of main saw blade spindle	4 400/min.
Max. depth of cut with scoring unit	100 mm (70 mm [45°])
Saw blade tilting	0° ÷ 45°
Max. width of cut	800 mm (1 050; 1 500 mm)
Scoring unit
Motor power of scoring unit	0,5 kW
Saw blade diameter	Ø 120 mm (100 mm)
Spindle diameter	Ø 20 mm (3/4")
Speed (drive with separate motor)	8 530/min.(10 230/min.[60Hz])
Spindle moulder
Motor power	3,0 kW (2,2 \| 3,7 kW)
Motor speeds	2 865/min.(3 438/min.[60Hz])
Spindle diameter	Ø 30 mm (35 \| 40 \| 50 \| 5/4" \| 5/4"/3/4")
Spindle speeds	1 400; 3 500; 6 000; 8 000/min.
	( 1 400; 3 500; 6 000; 8 000; 10 000/min )
Max. spindle stroke	140 mm
Spindle length	130 mm
Max. diameter of table opening	Ø 220 mm
Max. tool diameter under the table	Ø 175 mm
Max. tool diameter above the table	Ø 200 mm
Spindle tilting	-5° ÷ +45°
Machine dimensions
Length (with CV360 - 2 000 mm)	2 660 mm
Length (with CV360 - 2 600 mm)	2 970 mm
Length (with CV360 - 3 200 mm)	3 390 mm
Width	2 700 mm
Table height	892 mm
Max. height of machine	1 300 mm
Table size	1 314 x 479 mm
Suction dust hood diameter	100 mm
Gross weight	602 kg
Nett weight	598 kg
Alu sliding table
Table size	2 000 (2 600 \| 3 200) x 360 mm
Dimensions of supporting frame	1 240 x 650 mm
Length of cut	2 000 (2 600 \| 3 200) mm
Other parameters
Voltage / frequency	3x400V (3x230V \| 1x230V) / 50(60)Hz
Line safeguarding	16 A (25 A)
Noise level (without technology)	81,4 dB(A)
Noise level (with technology)	87,3 dB(A)
Acustic achievement	89,3 dB(A)
Acustic achievement (with technology)	93,0 dB(A)
