Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

Saw Motor power 3 kW (4 | 5,5 kW) Motor speeds 2 870/min.(3 444/min.[60Hz]) Max. saw blade diameter with scoring unit Ø 315 mm Spindle diameter 30 mm (1") Speed of main saw blade spindle 4 450/min. (3 500/5 000) Max. depth of cut 100 mm (70 mm [45°])

Saw
Motor power	3 kW (4 \| 5,5 kW)
Motor speeds	2 870/min.(3 444/min.[60Hz])
Max. saw blade diameter with scoring unit	Ø 315 mm
Spindle diameter	30 mm (1")
Speed of main saw blade spindle	4 450/min. (3 500/5 000)
Max. depth of cut	100 mm (70 mm [45°])
Saw blade tilting	0° ÷ 45°
Max. width of cut	1 050 (1 500) mm
Scoring unit
Motor power of scoring unit	0,5 kW
Saw blade diameter	Ø 120 mm (100 mm)
Spindle diameter	Ø 20 mm (3/4")
Speed	8 530/min.(10 236/min.[60Hz])
Machine dimensions
Length (with CV360 - 2 000 mm)	2 545 mm
Length (with CV360 - 2 600 mm)	2 845 mm
Length (with CV360 - 3 200 mm)	3 355 mm
Width	3 350 (3 800) mm
Table height	892 mm
Max. height of machine	1 130 (1 460 \| 1 700) mm
Table size	1 185 x 500 mm
Suction dust hood diameter	100 + 40 (60 \| 100) mm
Gross weight	610 kg
Nett weight	605 kg
Alu sliding table
Table size	2 000 (2 600 \| 3 200) x 360 mm
Dimensions of supporting frame	1 240 x 650 mm
Length of cut	2 000 (2 600 \| 3 200 ) mm
Other parameters
Voltage / frequency	3x400V (3x230V) / 50(60)Hz
Line safeguarding	16 A (25 A)
Noise level (without technology)	81,8 dB(A)
Noise level (with technology)	85,3 dB(A)
Acustic achievement	98,6 dB(A)
Acustic achievement (with technology)	102,1 dB(A)
