Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

DISPLAY TECHNOLOGY0.63” 3-LCD with MLARESOLUTION1024 x 768 XGA compression 1600 x 1200 UXGABRIGHTNESS2200 lumensCONTRAST RATIO500:1UNIFORMITY85%PROJECTIOM IMAGE (DIAGONAL)40~300 inchesZOOM/FOCUSManual Focus and Zoom Lens (Zoom Ratio 1.2:1)COLORS16.7

DISPLAY TECHNOLOGY	0.63” 3-LCD with MLA
RESOLUTION	1024 x 768 XGA compression 1600 x 1200 UXGA
BRIGHTNESS	2200 lumens
CONTRAST RATIO	500:1
UNIFORMITY	85%
PROJECTIOM IMAGE (DIAGONAL)	40~300 inches
ZOOM/FOCUS	Manual Focus and Zoom Lens (Zoom Ratio 1.2:1)
COLORS	16.7 million
ASPECT RATIO	4:3 native 16:9 compatible
PROJECTION LENS	F=1.6~1.88 f=18.6~22.3 mm
THROW RATIO	1.45~1.73
THROW DISTANCE	1.2 – 10 m (3.3 ~ 25 feet)
PROJECTION LAMP	200W UHP
DIGITAL KEYSTONE CORRECTION	Vertical +/- 30˚ (Manual and Auto)
SCANNING RANGE	H 31~ 92 kHz ; V 48~120 Hz
COMPUTER COMPATIBILITY	Resolution: 640X480 (Expand), 1024X768 (Native), 1280X1024(Compressed), 1600X1200(Re-sampling)
VIDEO COMPATIBILILITY	NTSC / NTSC 4.43 / PAL (including PAL-M,N) / SECAM/ PAL-60 Component video: 480i/p, 525i/p, 576i/p, 625i/p, 720p, 1080i, 1125i 50/60 Hz
INPUT TERMINALS	RGB: Mini D-sub 15 pin x 1, DVI-I x 1, Audio: mini jack x 2 Composite Video: RCA x 1, S-Video x 1, Audio: RCA(L,R) x2 Component Video: RCA x 3, Audio: RCA(L,R) x 2
OUTPUT TERMINALS	RGB: Min D-sub 15 pin x 1, Audio: mini jack x 1
SERVICE PORT TERMINAL	Mini DIN 8-pin
MOUSE CONTROL PORT	USB type B x 1
CONTROL TERMINALS	RS-232C D-sub 9 pin x 1 RJ45 LAN x 1 (Optional)
AUDIO SPEAKER	8W x 1
POWER CONSUMPTION	285W
DIMENSION (W x H x D)	325 x 96 x 260 mm (12.8” x 3.8” x 10.24”)
WEIGHT	3.2Kg (7.3 lbs)
POWER REQUIREMENTS	AC 100~240V, 50/60 Hz
FAN NOISE	33 dBA (ECO mode: 30 dBA)
ENHANCED FUNCTIONS	Auto search, Auto sync, Auto Ceiling, Auto Keystone and Auto Filter Alert Instant off ( 10 seconds cooling time and turn off) 7 display modes (natural, cinema, user, green board, powerful, video, presentation) Green power compliance- 4W power consumption at stand-by mode Optional LAN (RJ45) monitoring utility for remote management
REGULATIONS	UL, cUL, FCC, CE, CB, CCC
